MUSIC-HORN SPEAKER
■ TABLE OF CONTENTS
1. GENERAL DESCRIPTION
Thank you for purchasing TOA's Music-Horn Speaker.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your
equipment.
1. GENERAL DESCRIPTION
TOA's CS-530BS-EB/CS-660BS-EB Music-Horn speakers feature ABS resin enclosure and stainless
steel bracket for all weather durability.
These are comprised of a high-efficiency weather-resistant horn and a high quality sound cone speaker,
providing excellent speech and BGM clarity.
TOA's CS-530BS-EB/CS-660BS-EB are certified to the European Standard EN 54-24: 2008 and
International Standard ISO 7240-24: 2010, and are compliant with the British Standard BS 5839-8: 2008.
・Highly intelligible speakers suited to voice alarm, public address and BGM application by two way
system.
・Certified to EN 54-24, and ISO 7240-24, and compliant with BS 5839-8.
・All weather durability, water and dust protection to IP 66.
・Impedance change available by tapping changing located inside the terminal cover.
Traceability Information for EU (EMC directive 2004/108/EC); manufacturer:
Tel.: +49-(0)40-25 17 19-0 ♦ Fax: +49-(0)40-25 17 19-98 ♦ URL:
CS-530BS-EB/CS-660BS-EB Instruction Manual
TOA Electronics Europe GmbH
Süderstraße 282 ♦ 20537 Hamburg ♦ Germany
TOA Corporation
Instruction Manual
CS-530BS-EB/CS-660BS-EB
ﺘﺘﻌﻠق ﺒﻨ و اﺤﻰ اﻟﺴﻼﻤﺔ
ت
اﺤﺘﻴﺎطﺎ
www.toa.eu
1
Advertisement
Table of Contents
Related Manuals for Toa CS-530BS-EB
Summary of Contents for Toa CS-530BS-EB
- Page 1 These are comprised of a high-efficiency weather-resistant horn and a high quality sound cone speaker, providing excellent speech and BGM clarity. TOA’s CS-530BS-EB/CS-660BS-EB are certified to the European Standard EN 54-24: 2008 and International Standard ISO 7240-24: 2010, and are compliant with the British Standard BS 5839-8: 2008.
-
Page 2: Safety Precautions
Refer all servicing material damage and possible personal injury. to your nearest TOA dealer. Ensure that all screws are securely tightened. If they are loose after installation, the speaker could fall down, possibly resulting in personal injury. - Page 3 3. IMPEDANCE CHANGE Input impedance is factory pre-set to 330Ω (CS-530BS-EB), 170Ω (CS-660BS-EB). To change the impedance, change the terminal position located inside the terminal cover. [Note] These speakers are designed to be used for high impedance application. Never connect the speaker to low impedance line.
- Page 4 CS-530BS-EB/CS-660BS-EB Instruction Manual 4. INSTALLATION [Caution] Do not install the speaker face-up from a horizontal plane. If water accumulates in the horn, this may cause the speaker malfunction. Step 1. Fixing the bracket on the wall with screws. Step 2. Unscrew the back cover.
- Page 5 CS-530BS-EB/CS-660BS-EB Instruction Manual 5. DIMENSIONAL DIAGRAM ■ CS-530BS-EB ■ CS-660BS-EB TOA Corporation...
-
Page 6: Specifications
CS-530BS-EB/CS-660BS-EB Instruction Manual 6. SPECIFICATIONS CS-530BS-EB CS-660BS-EB Rated Power 330Ω (30W), 670Ω (15W), 1.3kΩ 170Ω (60W), 330Ω (30W), 670Ω (15W), Rated Impedance (7.5W), 2.7kΩ (3.75W) 1.3kΩ (7.5W) Sound Pressure Level 96dB (1m, 1W) 97dB (1m, 1W) Maximum S. P. L. - Page 7 CS-530BS-EB/CS-660BS-EB Instruction Manual ﻛﺘﻴب اﻟﺘﻌﻠﻴﻤﺎت ﺘﺘﻌﻠق ﺒﻨ و اﺤﻰ اﻟﺴﻼﻤﺔ ت اﺤﺘﻴﺎطﺎ . ً ﻴﺠب اﻟﺘﺄﻛد٬ ﻗﺒﻝ اﻟﺘرﻛﻴب أو اﻻﺴﺘﺨدام٬ ﻤن ﻗ ر اءة ﻛﺎﻓﺔ اﻟﺘﻌﻠﻴﻤﺎت اﻟﺘﻲ ﻤن ﺸﺄﻨﻬﺎ أن ﺘﻀﻤن اﺴﺘﺨداﻤ ﺎ ً آﻤﻨ ﺎ ً وﺼﺤﻴﺤ ﺎ .ﻴﻨﺒﻐﻲ اﻟﺘﺄﻛد ﻤن إﺘﺒﺎع ﻛﺎﻓﺔ ﺘﻌﻠﻴﻤﺎت اﻟﺤﻴطﺔ٬ و اﻟﺘﻲ ﺘﺸﻤﻝ ﺘﺤذﻴ ر ات ﻫﺎﻤﺔ و اﺤﺘﻴﺎطﺎت ﺘﺨص اﻟﺴﻼﻤﺔ أو أﻴ ﺎ ً ﻤﻨﻬﻤﺎ...
- Page 8 CS-530BS-EB/CS-660BS-EB Instruction Manual .اﺴﺘﺨدم اﻟﻌﻨﺎﺼر اﻟﻤﻨﺎﺴﺒﺔ أﺜﻨﺎء ﻋﻤﻠﻴﺔ اﻟﺘﺠﻤﻴﻊ. وﻤﺨﺎﻟﻔﺔ ﻗد ﻴؤدي إﻟﻰ ﺴﻘوط اﻟوﺤدة أو ﻫذﻩ اﻟﻌﻨﺎﺼر٬ ﻤﻤﺎ ﻴؤدي إﻟﻰ وﻗو ع ﺨﺴﺎﺌر ﺒﺸ ر ﻴﺔ ﻻ ﺘﻘم ﺒﺘرﻛﻴب اﻟوﺤدة ﻓﻲ أﻤﺎﻛن ﻋرﻀﺔ ﻟﻼﻫﺘ ز از اﻟﻤﺘﺒﺎﻴن. ﻗد ﻴﺘﺴﺒب اﻻﻫﺘ ز از اﻟﻌﺎﻟﻲ ﻓﻲ ﺘﻠف ﺤﺎﻤﻝ اﻟﺘرﻛﻴب٬ وﻤن اﻟﻤﺤﺘﻤﻝ أن ﻴؤدي ذﻟك إﻟﻰ ﺴﻘوط اﻟوﺤدة٬ و اﻟﺘﺴﺒب ﻓﻲ إﺼﺎﺒﺎت...
