Ruijie RG-EG V2 Series Routers Hardware Installation and Reference Guide
Power Module
DC Connector
EEE
PoE
Power Consumption
Working
Temperature
Storage
Temperature
Working Humidity
Storage Humidity
Fan
Temperature
Warning
EMC Standards
Safety Standards
Dimensions (without
rubber pads)
(W x H x D)
Weight
Use the power adapter provided by Ruijie.
Appearance
Figure 1-4 Appearance of RG-EG105G-P V2
AC input:
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 1.5A
Inner diameter: 2.1mm
Outer diameter: 5.5mm
Inner pole: positive
Outer pole: negative
Not supported
IEEE 802.3af/at, 54W max output
＜60W
0º C to 40º C (32º F to 104º F)
-40º C to 70º C (-40º F to 158º F)
10% to 90% RH
5% to 95% RH
N/A
Not supported
GB9254 CLASS A
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
GB4943-2011
EN 62368-1
206.5 mm x 28 mm x 108.5 mm (8.13 in. x 1.1 in. x 4.27 in.)
0.75kg
4
Product Overview
