Safety
3.4

Safety Marking

PROHIBITION SIGN
Symbole
WARNING SIGN
Symbole
REGULATORY SIGN
Symbole
OPERATING SIGNS
Symbole
6 / 42
Meaning
It is not allowed to be under hanging loads. Danger to life!
Caution! Danger of squeezing! Touch only at handles.
Meaning
Danger of squeezing the hands.
Meaning
Each operator must have read and understood the operating
instructions (and all safety instructions).
Meaning
Setting 170 bar for articulated shovels/roll mops
Setting 200 bar for wheel loaders
Setting the side clamping/ main clamping
Approx. 2 turns to the left to "+" = side clamping and main
clamping, open simultaneously.
Approx. 2 turns to the right to "-" = first the side clamping, opens
and only then does the main clamping open.
Lever for activating/deactivating side clamping
V2
Order-No Size:
2904.0210 30 mm
2904.0209 50 mm
2904.0204 80 mm
2904.0367 205x30 mm
Order-No Size:
2904.0221 30 mm
2904.0220 50 mm
2904.0107 80 mm
Order-No Size:
2904.0665 30 mm
2904.0666 50 mm
Order-No Size:
29040775 29x33 mm
29040774 30x45 mm
2904.0773 46x87 mm
