Invacare® LiNX
• the seating indicator switches off while the drive wheel
indicator flashes.

4.7 Connecting the remote

CAUTION!
Risk of unintended stops
If the plug of the remote cable is broken, the
remote cable may come loose while driving. The
remote could suddenly switch off when losing
power. This forces an unintended stop.
– Always check the plug of the remote for
damage. Contact your provider immediately in
case of a damaged plug.
Risk of damage to the remote
The remote plug and connector socket fit
together in one way only.
– Do not force them together.
1. Lightly push to connect the plug of the remote cable
and the connector socket. The plug must lock in place
with an audible click.
22 1608055-C
