Summary of Contents for Tektronix 4000-3
- Page 1 Supplement Grass Valley Model 4000-3 Wipes on Program Preset Upgrade Software Release 6.0R2 061-4154-00 First Printing: October, 1998...
-
Page 2: Contacting Tektronix
This document may not be copied, in whole or in part, or otherwise reproduced, except as specifically permitted under U.S. copyright law, without the prior written consent of Tektronix, Inc., P.O. Box 1000, Wilsonville, Oregon 97070-1000. TEKTRONIX is a registered trademark and Grass Valley is a trade- mark of Tektronix, Inc. - Page 3 October 19, 1998 Model 4000-3 Wipes on the Program/Preset Upgrade Introduction A new printed circuit board (PCB) has been added to the Tektronix Grass Valley Model 4000-3 Digital Switcher to allow the wipes on program preset functionality. The wipes on program preset function was an option for 4000-3 switchers ordered before April 10, 1998.
- Page 4 Version 6.0R2 Provided Materials A new upper printed circuit board (PCB), Tektronix Part #068977-00 (REV C). A set of new keycaps. Software upgrade diskette. (Version 6.0 or later). Required Tool (Not Provided) 5/16-inch nut driver. Step-By-Step Board and Keycap Upgrade Procedure Raise the lid of the switcher panel.
- Page 5 Model 4000-3 Wipes on the Program/Preset Upgrade Use a 5/16-inch nut driver to remove the eight white plastic nuts from the board stand-offs. Save the nuts for re-use. Remove the obsolete #068977-00 (REV. A or REV. B) PuP board. Install the new #068977-00 (REV. C) PuP board, using the eight white plastic nuts saved from the old board.
-
Page 6: Wipe Transitions
Note The wipes on program preset functionality is an orderable option for Model 4000-3 switchers ordered before April 10, 1998. This functionality now comes standard on all 4000-3s shipped after October 19th, 1998. Systems that were ordered in the interim will receive an upgrade kit as part of the purchase price. - Page 7 Model 4000-3 Wipes on the Program/Preset Upgrade PGM/PST Matte Subpanel With the new PGM/PST wipe software installed, there is different func- tionality for downstream keyer (DSK) background mattes, DSK matte fills, and DSK borderline mattes. The Matte subpanel provides control to the matte generators for down- stream keyers (DSKs), key borders, and backgrounds.
- Page 8 PGM/PST secondary wipe generator for the purpose of wash operations. Matte and Wash Operator’s Summary for Model 4000-3 with WPP All Matte and Wash controls for Key Matte Fills are stored in the [DSK] level for E-MEM recall,...
-
Page 9: Wipe Menus
Model 4000-3 Wipes on the Program/Preset Upgrade PGM/PST Wipe Border Mattes Control for the PGM/PST primary wipe borders is under the WIPE BORDER menu. To open the WIPE BORDER menu, if the PGM PRI WIPE button is dele- gated, the BORD button can be pressed. Turning BORD on will open the program preset wipe border menu. - Page 10 Version 6.0R2 Wipe Positioner The wipe positioner delegation buttons have changed from the single- button delegations of M/E 1 PRI, M/E 1 SEC, M/E 2 PRI, M/E 2 SEC, M/ E3 PRI, and M/E 3 SEC to M/E 1, M/E 2, M/E 3, PGM PST delegations plus a PRI and SEC delegation.
