Taylor 430 Service Manual page 37

Model 430 Exploded View Parts Identification List
ITEM DESCRIPTION
1 BELT−V−4L350
2 PULLEY−AK49 X 5/8
3 SCREW−5/16−18X5/8 SERR
4 GEAR A.*REDUCER 4.92:1
SERVICE
5 SHELL A.−INSULATED
5a BEARING−REAR SHELL
5b GUIDE−DRIP SEAL
5c NUT−BEARING
5d O−RING−PKG *25 TO BAG*
(1−1/16 OD X .070 WALL)
6 DISC−PROBE *SQ HOLE*
7 PROBE A.−MIX LOW−HT
8 SPACER−PROBE *SQ HOLE*
9 WASHER−#10 EXTERNAL
TOOTH LOCK
10 NUT−10−32 HEX MACHINE
SCREW
11 VALVE−EPR 1/4S
12 PANEL−REAR
13 COVER−CONTROL BOX
14 CONTROL A. (SEE PAGE 35)
15 VALVE−EXP−AUTO−1/4S X1/4
16 GUIDE A.−DRIP PAN
17 MOTOR−FAN 50 WATT
18 FAN−5 BLADE 12" PUSH
22DEG CCW
19 SHROUD−FAN
20 CONDENSER−AC 12LX16H
21 PANEL−SIDE L
22 SCREW−10−32X3/8 SLTD
23 DRYER−FILTER 1/4 X 1/4
Model 430
PART NO. ITEM
004194 24
051394
25
017326
015985−SER
26
X52574−SER
27
032511
28
028992
29
028991
018432
30
31
030965
32
X42077
030966
33
002681
005598
34
022665
35
049325
36
049321
37
X50663−
38
046365
39
X49327
40
029770−
41
049009
42
048877
43
048935
44
049639
*45
024298
*NOT SHOWN
048878
33
DESCRIPTION
SWITCH A.−TORQUE
(SEE PAGE 37)
SWITCH A.−DRAW
(SEE PAGE 36)
LIGHT−AMBER−RECT−12VDC
ADD MIX
LIGHT−AMBER−RECT−12VDC
MIX OUT
PANEL A.−FRONT
SWITCH−ROCKER
AUTO/WASH
TUBE−CAP..036IDX.087OD X 9
PULLEY−AK27−1/2
MOTOR−1/4 HP
CORD−POWER−125V−NEMA
5−20P−6'L (115V)
CORD−POWER−230V−15A
PLUG−75"L (208−230V)
COMPRESSOR
AKA9462ZXA−AK172BT
NUT−5/16−18 FLANGE NUT
WASHER−3/8 USS FLAT CR3
SLEEVE−MOUNTING−COMP
GROMMET−COMPRESSOR
MOUNT
SCREW−5/16−18X1−1/2 HEX
SUPPORT−DRIP TRAY
STUD−NOSE CONE
WASHER−FREEZER STUD
PROBE A.−MIX OUT−SQ HOLE
SWITCH−PRESSURE 440 PSI
PANEL−SIDE R
PART NO.
X50895−SER
X80870
052486−02
047142−02
X50678
048420
051049
016190
014477−
085093
025340−27
049302−
017327
000653
039920
039919
001894
049318
013496
049032
X41348
048230
049640
140425
Parts
