Elo TouchSystems 1928L User Manual

5000 series 19” lcd desktop touchmonitor
Hide thumbs Also See for 1928L:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Touchmonitor User Guide
1928L 19" LCD Desktop Touchmonitor
5000 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1928L and is the answer not in the manual?

Questions and answers

Related Manuals for Elo TouchSystems 1928L

Summary of Contents for Elo TouchSystems 1928L

  • Page 1 Touchmonitor User Guide 1928L 19” LCD Desktop Touchmonitor 5000 Series...

  • Page 2: User Guide

    User Guide 1928L 19” LCD Desktop Touchmonitor Revision C P/N E116103...

  • Page 3: Trademark Acknowledgments

    Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments Elo Touchsystems AccuTouch and IntelliTouch are trademarks of Tyco Electronics Corporation. Other product names mentioned herein may be trademarks or registered trademarks of their re-...

  • Page 4: Warnings And Cautions

    Warning • Danger - Explosion hazard. Do not use in the presence of flammable anesthetics, and other flammable materials. • To prevent fire or shock hazards, do not immerse the unit in water or expose it to rain or moisture. •...

  • Page 5: Caution

    Caution • Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. • This unit must follow the national requirement and local state laws to dispose unit. • Before connecting the cables to your Elo touchmonitor, make sure all components are powered OFF.

  • Page 6: Caution-Life Support

    CAUTION-Life Support Care must be taken when this touchmonitor is a critical component of a life support system or device. In case of failure of this touchmonitor, appropriate redundant systems should be incorporated into the system or device to prevent injury to the user or patient. The following should be an integral part of the safety design of a life support system or device using this touchmonitor for a critical function.

  • Page 7: Classification

    Classification With respect to electrical shock, fire in accordance with UL60601-1 and CAN/CSA C22.2 No. 60601-1 This monitor is a Class I (GROUNDED) DEVICE. These displays are classified NO APPLIED PARTS EQUIPMENT. Protection against harmful ingress of water: INGRESS PROTECTION (IPX1) This monitor shall be classified as ORDINARY EQUIPMENT, not intended or evaluated for use in the presence of flammable anesthetic mixture with air, oxygen, or nitrous oxide.

  • Page 8: European Standards And Classifications

    European Standards and Classifications Standards: EN 60601-1-2: 2001 The EMC limits and test methods are referred to the following standards: Emission: CISPR 11: 2003+A1:2004 AS/NZS CISPR 11:2004 (Group 1, Class B) EN55011: 1998+A1: 1999+ A2: 2002, (Group 1, Class B) IEC 61000-3-2: 2000, (Refer to note * below) IEC 61000-3-3;...

  • Page 9: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic emissions The ET1928L is intended for use in the electromagnetic environment specified below. The customer or the user of the ET1928L should assure that it is used in such an environment. Emissions test Compliance RF emissions...
  • Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic immunity The ET1928L is intended for use in the electromagnetic environment specified below. The customer or the user of the ET1928L should assure that it is used in such an environment. Immunity test IEC 60601 test level...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacturer’s declaration-electromagnetic immunity The ET1928L is intended for use in the electromagnetic environment specified below. The user of the ET1928L should assure that it is used in such an environment. Immunity test IEC 60601 test level Conducted RF...
  • Page 12 Recommended separation distance between portable and mobile RF communications equipment and the ET1928L for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING Recommended separation distances between portable and mobile RF communications equipment and the ET1928L The ET1928L is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ET1928L can help prevent electromagnetic interference by maintaining a mini- mum distance between portable and mobile RF communications (equipment) and the ET1928L as recommended below according to the maximum output power of the communications equipment.

  • Page 13: Table Of Contents

    Warnings and Cautions ... iv Warning ... iv Caution ... v Caution-Life Support ... vi Classification ... vii European Standards and Classifications Standards ... viii Chapter 1 INTRODUCTION Product Description ... 1 LCD Display Performance Features ... 2 19 inch TFT LCD Display Panel ... 2 External Medical Grade Power Supply ...

  • Page 15: Introduction

    NTRODUCTION Product Description The 1928L is a medical display designed to present information to the operator and the customer. The 1928L is available in serial and USB(combo) touch interface as well as non-touch. The 1928L functionally consists of a 19” LCD main display with a touchscreen. The main display element is a 19”...

  • Page 16: Lcd Display Performance Features

    Display color Typical vertical viewing angle Typical horizontal viewing angle External Medical Grade Power Supply The 1928L is powered by an external medical grade universal input AC power source. Power supply: • AC power: Input voltage 100 -240 VAC, 1.0A •...

  • Page 17: Installation And Setup

    C H A P T E R NSTALLATION ETUP This chapter discusses how to install your LCD touchmonitor and how to install Elo TouchSystems driver software. Unpacking Your Touchmonitor Check that the following items are present and in good condition: LCD monitor VGA cable USB cable...

  • Page 18: Product Overview

    Product Overview Main Unit Back Unit Side View Elo Touchmonitor User Guide...

  • Page 19: Base Bottom View

    Base Bottom View Kensington Lock The Kensington lock is a security device that prevents theft. To find out more about this secu- rity device, go to http://www.kensington.com.

  • Page 20: Touch Interface Connection

    Touch Interface Connection Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. STEP 1-Connecting the Video Cable • Tilt the screen up and back to access the connection ports. •...

  • Page 21: Step 2 Connecting The Serial/Usb Cable

    STEP 2-Connecting the Serial and USB Touchscreen Cable CONNECTORS ON THE UNDERSIDE USB CONNECTOR FEMALE 9-PIN SERIAL TOUCHSCREEN CONNECTOR • Connect the female end of the serial (RS-232) cable to the serial port on your PC, or connect the USB( ) touchscreen cable to the USB( ) touchscreen connector on the back of your touchmonitor.

  • Page 22: Step 3 Connecting The Speaker Cable

    STEP 3-Connecting the Speaker Cable • Connect the light blue end of the speaker cable to the light blue speaker port to the monitor (audio in). • Connect the lime (light green) end of the speaker cable to the lime speaker port on the computer (audio out).

  • Page 23: Step 4 Connecting The Power Cable

    STEP 4-Connecting the Power Cable CONNECTIONS ON UNDERSIDE POWER Depending on where you live, you will use either the European or US/Canadian power cable. • Connect the female end of the power cable to the medical grade power adaptor. • Connect the brick power cable into the power port on the touchmonitor.

  • Page 24: Mounting The Display

    Mounting the Display Your medically certified touchscreen display conforms to the VESA Flat Panel Monitor Physical Mounting Interface (FPMPMI) standard. The FPMPMI standard defines a physical mounting interface for flat panel displays. Your display conforms to the corresponding standards for flat panel display mounting devices, such as for walls and table arms.

  • Page 25: Rear Mounting Using The Vesa Interface

    Rear Mounting Using the VESA Interface 1 If the display is already connected to a pedestal, remove the four screws that connect the pedestal to the display (refer to Figure2-1 , item 2 Reinstall the four screws into the VESA interface mount. Ensure that the monitor is positioned with the correct side up.

  • Page 26: Optimizing The Lcd Display

    Optimizing the LCD Display To ensure the LCD display works well with your computer, configure the display mode of your graphic card to make it less than or equal to 1280 x 1024 resolution, and make sure the timing of the display mode is compatible with the LCD display.

  • Page 27: Operation

    C H A P T E R PERATION About Touchmonitor Adjustments Your touchmonitor will unlikely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1280 x 1024 at 60-75 Hz.

  • Page 28: Side Panel Controls

    Side Panel Controls Control 1 Menu/Exit 4 Select 5 Power Switch 3-14 Elo Touchmonitor User Guide Function Display/Exits the OSD menus. 1. Enter contrast of the OSD. 2. Increase value of the adjustment item. 3. Shuffle item clockwise. 1. Enter audio volume adjustment. 2.

  • Page 29: Controls And Adjustment

    Controls and Adjustment OSD Menu Functions To Display and Select the OSD Functions: 1 Press the Menu key to activate the OSD menu. 2 Use on the monitor. The parameter will be highlighted when selected. 3 To quit the OSD screen at any time during the operation, press the Menu key. If no keys are pressed for a short time period, the OSD automatically disappears.

  • Page 30: Osd Control Options

    OSD Control Options Control Contrast Brightness V-Position H-Position Recall Defaults Color Balance Audio Volume Sharpness Phase Clock OSD H-Position OSD V-Position OSD Time Auto-Adjust OSD Language Input Select 3-16 Elo Touchmonitor User Guide Description Increases or decreases contrast. Increases or decreases brightness. Moves the screen up or down.

  • Page 31: Power Display & Power Saving

    Power Display & Power Saving General Power Saving Mode Mode Sleep Power-Save (No Input) • The LCD panel background is cut when there is no signal input (AC line power consump tion of 7w or less). Note: Display Angle For viewing clarity, you can tilt the LCD forward (up to -5 degrees) or backward (up to 90 degrees).
  • Page 32 3-18 Elo Touchmonitor User Guide...

  • Page 33: Appendix A

    If you are experiencing trouble with your touchmonitor, refer to the following table. If the prob- lem persists, please contact your local dealer or our service center. Elo Technical Support num- bers are listed on page 31 of this manual. Solutions to Common Problems Problem The monitor does not respond...
  • Page 34 3-20 Elo Touchmonitor User Guide...

  • Page 35: Native Resolution

    The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. 1928L native resolution is 1280 x 1024. In almost all cases, screen images look best when viewed at their native resolution. You can lower the resolution setting of a monitor but not increase it.
  • Page 36 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1280 pixels horizontally by 1024 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.

  • Page 37: Touchmonitor Safety

    This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case.

  • Page 38: Care And Handling Of Your Touchmonitor

    Care and Handling of Your Touchmonitor The following tips will help keep your Elo touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the external power adaptor or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning.

  • Page 39: Technical Specifications

    Display Modes Your Elo touchmonitor is compatible with the following standard video modes: Item Resolution 640 x 350 720 x 400 640 x 480 640 x 480 640 x 480 640 x 480 800 x 600 800 x 600 800 x 600 800 x 600 832 x 624 1024 x 768...

  • Page 40: Touchmonitor Specifications

    Touchmonitor Specifications Parameter LCD Display Pixel Pitch Display Mode Native Contrast Ratio Brightness AccuTouch IntelliTouch Response Time Display Color Viewing Angle Input Signal Signal Connector Front Control Plug & Play Touch Panel Power External Power Supply* Monitor Environmental Temp. Operating Storage/Transportation -20 Humidity (non-condensing) Operating...

  • Page 41: Power Supply Cord Selection

    Power Supply Cord Selection North America Power Supply Cord Detachable, UL Listed, Type SJT 3 conductor, 18 AWG, configured load fittings terminating in molded on parallel blade. Grounding type hospital grade attachment plug, rated at a minimum of 3 amperes. Basic Cord Type SP-2 SP-3...

  • Page 42: Cord Selection For Other Than North America

    Cord selection for other than North America For 100 V ac or 220/230/240 V ac operation, the unit is provided with IEC 320 flexible power cords properly configured for the intended country other than North America. The NOMINAL cross-sectional area (mm2 Cu) must be 0,75. For assistance in selecting the proper power cord contact the Elo distributor in your area or contact Elo (see Appendix D, page 23) Country Argentina...
  • Page 43 HAR FLEXIBLE CORD Approval Organization Comite Electrotechnique Belge (CEBEC) Verband Deutscher Elektrotechniker (VDE) e.V. Prufstelle Union technique de l'Electricite (UTE) Instituto Italiano del Marchio di Qualita (IMQ) British Approvals Service for Electric Cables (BASEC) N> V. KEMA SEMKO AB Svenska Elektriska Materielkontrollanstalter Österreichischer Verband fur Elektrotechnik (ÖVE)

  • Page 44: Accutouch (Resistive) Touchscreen Specifications

    AccuTouch (resistive) Touchscreen Specifications Mechanical Positional Accuracy Touchpoint Density Touch Activation Force Surface Durability Expected Life Performance Sealing Optical Light Transmission (per ASTM 90% D1003) Visual Resolution Gloss (per ASTM D2457 using a 60-degree gloss meter) Environmental Chemical Resistance Electrostatic Protection (per EN 61 000-4-2, 1995) C-30 Elo Touchmonitor User Guide...

  • Page 45: Intellitouch Touchmonitor Specifications

    IntelliTouch(acoustic) Touchmonitor Specifications Mechanical Positional Accuracy Touchpoint Density Touch Activation Force Surface Durability Expected Life Performance Sealing Optical Light Transmission (per ASTM D1003) Visual Resolution Gloss (per ASTM D2457 using a 60- degree gloss meter) Standard deviation of error is less than 0.080 in. (2.03 mm). Equates to less than ±1%.
  • Page 46 C-32 Elo Touchmonitor User Guide...

  • Page 47: Contact Elo

    A P P E N D I X Contact Elo Elo TouchSystems 301 Constitution Drive Menlo Park, CA 94025 1-800-ELO-TOUCH (1-800-356-8682) www.elotouch.com D-33...
  • Page 48 D-34 Elo Touchmonitor User Guide...

  • Page 49: Regulatory Information

    EGULATORY I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.
  • Page 50 D) General Information to all Users: This equipment generates, uses and can radiate radio fre- quency energy. If not installed and used according to this manual the equipment may cause interference with radio and television communications. There is, however, no guarantee that interference will not occur in any particular installation due to site-specific factors.

  • Page 51: Warranty

    ARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 3 years. Seller makes no warranty regarding the model life of components.
  • Page 52 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.

  • Page 53: Index

    Numerics ET1928L-XXWA-1-G About touchmonitor Adjustments, 11 AccuTouch(resistive)Touchscreen Specifications, 30 Audio Volume, 16 Auto-Adjust, 16 Back Unit, 4 Base Bottom View, 5 Brightness, 16 Care and Handling of your Touchmonitor, 24 Caution-Life Support, vi Classification, vii Clock, 16 Color Balance, 16 Connecting the Video Cable, 6 Connecting the Serial and USB Touchscreen Cable, 7 Connecting the Speaker Cable, 8...
  • Page 54 Rear View, 10 Rear Mounting Using the VESA Interface, 11 Recall Defaults, 16 Regulatory Information, 36 Sealing, 30, 31 Sharpness, 16 Side Panel Controls, 12 Side View, 4 Solutions to Common Problems, 19 European Standards and Classifications, vii Standards, vii Surface Durability, 30, 31 SVGA, 21 Technical Specifications, 25...

  • Page 55: Product Information

    Check out Elo TouchSystems Web site! www.elotouch.com Get the latest... • Product information • Specifications • News on upcoming events • Press release • Software drivers Getting in Touch with Elo To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply call the office nearest you: North American Europe...
