ZKTECO White LCD Serials User Manual
Version: 3.0.1
Date: June, 2011
Introduction:
This document mainly introduces the windows and operations of white
LCD serials products. About the install process, please refer to the
Installation Guide.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the White LCD Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZKTeco White LCD Series

Summary of Contents for ZKTeco White LCD Series

  • Page 1 ZKTECO White LCD Serials User Manual Version: 3.0.1 Date: June, 2011 Introduction: This document mainly introduces the windows and operations of white LCD serials products. About the install process, please refer to the Installation Guide.

  • Page 3: Table Of Contents

    Table of Contents Contents 1. Using Instruction ................- 1 - 2. Basic Concepts ................- 4 - 2.1 User Enrollment ..................- 4 - 2.2 User Verification ..................- 4 - 2.3 Threshold ....................- 5 - 2.4 User ID Numbers ..................- 5 - 2.5 Privilege Levels ..................- 6 - 2.6 Initial Interface....................- 6 - 3.
  • Page 4 ZKTECO White LCD Serials User Manual 3.6 Administrator Enrollment .................- 22 - 3.7 Delete Enrolled Data.................- 23 - 4. Device Settings ................- 25 - 4.1 System Settings..................- 25 - 4.1.1 Date Time Setting................- 26 - 4.1.2 Language Setting ★.................- 26 - 4.1.3 Date Format..................- 27 -...
  • Page 5 Table of Contents 6. USB Disk Management ★ ............- 68 - 6.1 Download Attendance Data...............- 68 - 6.2 Download User Data.................- 69 - 6.3 Upload User Data..................- 69 - 6.4 Download SMS ★...................- 69 - 6.5 Upload SMS ★..................- 70 - 7.
  • Page 6 ZKTECO White LCD Serials User Manual Remote Server Solution ................- 107 - iClock Time & Attendance................- 109 - Web Server Access Control................- 110 - Collect IP Address Automatically ..............- 111 - About Wiegand ..................... - 112 - SOAP ......................

  • Page 7: Using Instruction

    1. Using Instruction 1. Using Instruction Thanks for using our product. Please read all safety and operation instruction before the product is operated, to avoid the unexpected damage to the device. Please do not place the product in the place with strong light, because the strong light may significantly affect the fingerprint scanning, and thus cause the fingerprint verification fail.
  • Page 8 ZKTECO White LCD Serials User Manual 2. Recommended Fingerprint Enroll fingerprint by pressing index finger, middle finger or ring finger (thumb and little finger are clumsy). 3. How to press the fingerprint 1) Proper press: Make finger center pressed on the sensor window...
  • Page 9 1. Using Instruction 4. LED indicator status: Normal work: Green light blinks each second. Failure authentication: Red light shines for 3 second Verification successful: Green light shines for 3 second Note: If the fingerprint device LED don’t follow above description. Please contact us to get technical assistance. 5.

  • Page 10: Basic Concepts

    2. Basic Concepts 2. Basic Concepts This section contains definitions and descriptions of the fingerprint identification system concepts, including:  User Enrollment  User Verification  Match Threshold  User ID Numbers  Privilege Levels The two most important Functions of the device are user enrollment and user verification.
  • Page 11 2. Basic Concepts Verification occurs when a user either enters an ID number or places a finger on the fingerprint sensor, then input password for comparison with the stored template. 2.3 Threshold The Threshold establishes a balance between False Acceptance Rate (FAR) and False Rejection Rate (FRR).

  • Page 12: Privilege Levels

    ZKTECO White LCD Serials User Manual ID numbers are normally inputted by the keypad, but they can be called up by other means of such as RF Card, Mifare Card (the realizing function condition is that there is card reader in the device).

  • Page 13: Enrollment And Verification

    3. Enrollment and Verification 3. Enrollment and Verification This chapter describes how to enroll and verify users on the Fingerprint verification system. The following topics are included:  Enrolling user  Testing an enrollment  Enrolling an auxiliary fingerprint for user ...

  • Page 14: Fingerprint Enrollment

    ZKTECO White LCD Serials User Manual To start the enrollment process, verifies the administrator identify first: Press Menu, the device prompt administrator confirm, enter your ID number or fingerprint, and then verify your identity. Note: If there is no administrator in the system, you will not be prompted for verification.

  • Page 15: Password Enrollment

    3. Enrollment and Verification New Enroll 00011-0 OK [Save] 4) Press OK to save the enrolled fingerprint, and finish the fingerprint enrollment process. If you failed to enroll the fingerprint, you are prompted to try again. And you must restart the verification procedure from the step 2.

  • Page 16: Fingerprint & Password

    ZKTECO White LCD Serials User Manual 4) Input your password, the following appears: New Enrollment Input Pwd ***** Pwd Affirm ***** 5) Input the passwords again, press OK, the following appears: New Enroll Note: 00006-P 00006-P The last letter P means password.
  • Page 17 3. Enrollment and Verification 3) Input the password (1 to 65534), press OK, the following appears: New Enroll 00008-0 Please finger……ESC 4) If you press the same finger successfully for three times in a row, the following appears: New Enroll Input Pwd: ***** 5) Input your password, the following appears: New Enroll...

  • Page 18: Id Card Enrollment

    ZKTECO White LCD Serials User Manual 3.1.4 ID Card Enrollment ★ 1) Press the Menu button to enter the User enroll, access Reg RFID, press OK, the following appears: RFID New Enroll？ 2) Press OK, the following appears: New enroll Enroll No: 00010 3) Input the enroll number (1 to 65534).

  • Page 19: Hid Card Enrollment

    3. Enrollment and Verification New enroll Note: 00010-C 000010-C The least letter C means ID card 6) Press ESC key to cancel the new enrollment, press OK to save enrolled data, so that complete registering ID card process. Note: ID card is an optional function on the fingerprint device, if you want to customize fingerprint device with ID card function, please contacts our market supporter and sale.
  • Page 20 ZKTECO White LCD Serials User Manual FPCardMng ▼ Create PINCard ►Enroll FPCard Create FPCar Reg FPCard Unreg FPCard Empty FPCard Dump FPCard 1. Create PIN Card (Create PIN card): Use the registered user in the fingerprint device to Create PIN card, user may use the card to identify himself, and don’t need to place the finger.

  • Page 21: Enrollment Testing

    3. Enrollment and Verification 6. Erase fingerprint from Fingerprint (Empty FP Card): Clear all data (fingerprint, PIN) on the fingerprint card. 7. Copy Fingerprint from card. (Dump FP Card): Copy a fingerprint from a card to Fingerprint device, it is able to directly track attendance by fingerprint after finish this operation process.

  • Page 22: Verification Modes

    ZKTECO White LCD Serials User Manual This operation procedure is same as above enroll new user operation, except the text “Backup Enroll” display on the top of the interface. Note: Where system memory permits, it is advisable to have at least two fingers enrolled for a long-term user.
  • Page 23 3. Enrollment and Verification If the test is successful, it will say “Thank you”, the following appears: FP Verify Enroll No 00001 Verified！ If your identity cannot be verified, you are prompted to try again, the following appears: FP Verify Place Finger Agn！...

  • Page 24: Password Verification

    ZKTECO White LCD Serials User Manual If your identity cannot be verified, you are prompted to try again, the following appears: FP Verify Place Finger Agn！ The device returns to the start-up window. 3.4.2 Password Verification To start the enrollment process, enter your ID number, the following...

  • Page 25: Card Verification

    3. Enrollment and Verification Pwd Affirm Enroll No 00008 Error Pwd！ 3.4.3 Card Verification ★ Just swipe the enrolled card near to the card reader area by the proper way, the user can verify his identity. 4.4.4 Mifare Card Verification ★ If the Mifare card has been used as created PIN card, need to enter Menu ->...

  • Page 26: Prompts For Successful Enrollments

    ZKTECO White LCD Serials User Manual Verifying FPCard 00009 Place Finger…… Any key to Cancel Press the finger on the sensor surface, the following appears: Verifying FPCard 00009 Please move finger Any key to Cancel If the test is successful, it will say “Thank you”, the following appears:...
  • Page 27 3. Enrollment and Verification fingerprint verification quality, the following hints appear. Table: Common reason for enrollment failure or bad quality Trouble Solution Fingerprints Solve the dry problem that rubs the dry finger with palm. too dry or dirty If the fingerprint is dry, you should adopt the way of wetting up the finger, such as brow air over finger.

  • Page 28: Administrator Enrollment

    ZKTECO White LCD Serials User Manual 3.6 Administrator Enrollment In order to prevent the unauthorized personal change the option of the device, the device provide an option to set administrator. Operations: 1) Press Menu key to enter the device menu, after verify successfully,...

  • Page 29: Delete Enrolled Data

    3. Enrollment and Verification administrator (supervisor) authorization, and more details please refer to 2.5 Privilege Levels. The enrollment way is same as user enrollment, for details please refer to 3.1 User Enrollment. 3.7 Delete Enrolled Data If a user wants to be deleted, you can take the following steps to cancel the user.
  • Page 30 ZKTECO White LCD Serials User Manual Delete Datum UserID 00008 5) Input the number you want to cancel, press OK to confirm, go on next operation, follow the prompt on the window to cancel user. - 24 -...

  • Page 31: Device Settings

    4. Device Settings 4. Device Settings Press the Menu, and then verify your identity. The following appears: Menu User Manage Options Sys Info Access Options, presses OK, the following appears: Options ▼ System Opt Power Mng Comm Opt Log Opts Access Option Alarm Cnt Group VerType...

  • Page 32: Date Time Setting

    ZKTECO White LCD Serials User Manual Lock Unlock Adv Option 4.1.1 Date Time Setting Access Date Time, the following appears: Date Time 2006-01-02 08:24:35 To change the date, press▲/▼ key, then input the correct date and time, press OK to save.

  • Page 33: Date Format

    4. Device Settings System Opts ▼ Opc.Sist. ▼ Fecha/Hora Date Time Language Idioma Spai Adv option Opc.Avanz. English Spain Note: This fingerprint device does not provide this option that follows that standard approved for use with this device. If you need this function, please contact our market supporter or salesman.

  • Page 34: Lock

    ZKTECO White LCD Serials User Manual 4.1.4 Lock ★ The Lock means the duration of lock drive, fingerprint device controls the time how long to open electronic lock. Select this option, and press OK key to enter setup, select number through digital key, press ESC to exit and save the setting.
  • Page 35 4. Device Settings DLST ▼ ►DLST Date Fmt Mode1 Enter DLST Standard Change the daylight saving time to Yes, after setting completed, press OK to save, this setting will take effect. If you change it to "No", then daylight saving time function will be ineffective. 2) After the daylight saving time function is activated, it is need to configure starting and end time of daylight saving time.

  • Page 36: Advanced Setting

    ZKTECO White LCD Serials User Manual Note: 1. If the begin month of the daylight saving time that you set is bigger than at the end of time, that means the setting is over a year. Like this: begin at 2007-9-1 4:00 and end at 2008-4-1 4:00.
  • Page 37 4. Device Settings Clr admin pri Show Score Match Thr Only 1 to 1 1:1 thr Two sensor Voice No.Card Only R.card Only FP Card Only Upd firmware Remote Auth Auth Server Work code Button Beep AdjVol(%) Alg Ver Print Anti-PB Note: The menu above is including the optional options.
  • Page 38 ZKTECO White LCD Serials User Manual 7. Only 1 to 1: Whether the ID number must be input. 8. 1:1 Threshold: Set the threshold for using of ID + fingerprint verification. 9. Two Sensors ★: If need to connect an external sensor, choose the option as “Yes”.
  • Page 39 4. Device Settings There are four modes to select (NL, LN NO, LO) in the fingerprint device. NL: Indicate that firstly perform network verification then local verification. LN: First perform local verification then go on network verification. NO: Indicate only go on remote verification, only remote database has fingerprint to pass verification.

  • Page 40: Power Management

    ZKTECO White LCD Serials User Manual 22. Anti-pass back: There are four options: none, out, in, in-out, for details, please refer to Appendix Anti-pass back Function. Note: 1) Additional fingerprint sensor and upgrade firmware are only valid for these fingerprint devices that is provided with USB port.
  • Page 41 4. Device Settings Bell Delay Scheduled Idle Idle min Lock PWRBut N WebMaster IP Time alter state This product uses smart power management system, supports the time switch and idle features, it can satisfy the user’s different demands. 1. Shutdown: Auto shutdown follows the schedule. Select this item.

  • Page 42: Time Status Selection

    ZKTECO White LCD Serials User Manual assigned hour, the ringing will stop automatically. 6. Web Master IP ★: Set IP address of PC which has been installed Web server. 7. Adjust volume ★: If you don’t satisfy speaker to play MP3 value of the fingerprint device, you can use the function to adjust it.
  • Page 43 4. Device Settings schedule table. Time State Selection: When time up to the scheduled time, the fingerprint device will automatically switch selected state at IN or OUT by your setting in state schedule table. Currently check condition will appear on the initials interface of fingerprint device. How to set the time state selection: Setup time state selection 1.
  • Page 44 ZKTECO White LCD Serials User Manual 4. Press OK key enter the following interface, directly input time you want via figure key: Changeoff Check-Out ▼ ►Time1 8: 30 Time2 Time3 5. Press “▲/▼” key to select time you want set newly, as the following picture.

  • Page 45: Communication Setting

    4. Device Settings 2. Select time you want cancel, take example as the time 1. Press OK key as follow picture: Time1 Set time function？ 3. Press ESC to cancel, the time will be canceled. Changeoff checkout ▼ ►Time1 Time2 Time3 Time4 4.
  • Page 46 ZKTECO White LCD Serials User Manual Net speed Auto IP address Net Mask Gateway TCP/IP RS232 RS485 Link code Extern Modem The device fully supports RS232, RS485, TCP/IP, whether the device are used to a Single Unit or Link to Networking, it will satisfy the user’s demands.

  • Page 47: Log Options

    4. Device Settings may connect with additional Modem. For details, please refer to Appendix Modem Function. Note: 1) If the fingerprint device is provided with Getaway and Sub mask, Ethernet option will not exist in it, which is defaulted as Ethernet is in opening.
  • Page 48 ZKTECO White LCD Serials User Manual function does not exist in the fingerprint device which is used in T&A and Simple Access Control. Enter the Access Option, press OK, the following appears: Access Option ▼ ►Define TZ/TP User Acc Opts...

  • Page 49: Access Options Introduction

    4. Device Settings apply, Normal Open is defined that Thee door can be set to a Passage Mode in the normal condition, Normal Close means that the door is close in the normal work condition.. 8. Duress Alarm Option ★: If the fingerprint registered has been authenticated the system will send an alarm signal to prostate someone is forced to open door.
  • Page 50 ZKTECO White LCD Serials User Manual Simply put, conditions of registered user can unlock door are: 1. The group that user belongs to should be in unlocking combination (also this group can be in unlocking combination with other groups, but it is required to unlock door together with them).

  • Page 51: Access Verification Flow

    4. Device Settings 4.5.2 Access Verification Flow - 45 -...

  • Page 52: Function Description

    ZKTECO White LCD Serials User Manual 4.5.3 Function Description 4.5.3.1 Time Period Time period is the minimum time period unit of Access Options. Whole system can be defined with maximum 50 time periods. And 7 time regions (i.e. one week) can be set in each time period. Each time region is effective time period in 24 hours of a day.
  • Page 53 4. Device Settings Press OK to enter setting of time period 1 and screen displays as follows: Def Time Period 1 ▲ Sun 00:00-23:59 Mon 00:00-23:59 Tue 00:00-23:59 Wed 00:00-23:59 Thu 00:00-23:59 Fri 00:00-23:59 Sat 00:00-23:59 Definition of time period 1 above is all-day open, i.e. factory default status.
  • Page 54 ZKTECO White LCD Serials User Manual 4.5.3.2 Grouping Function An Access Group allows users to be given standard access for the workplace. Different departments may have different access privileges and some corporation’s employers who are on shift duties, and may need different access levels for each shift, depending upon their time of entry and exit from the workplace.
  • Page 55 4. Device Settings 3) There are 3 time periods in GRP TZ Define. Relationships among these 3 time periods are “OR”. GRP 1Dflt TZ ▲ 4) Group 1 is effective in time periods of 1, 8 and 40, and can also select other defined time periods.
  • Page 56 ZKTECO White LCD Serials User Manual 4.5.3.3 User Access Options User Access Options is to process correlative setting according to user’s requirements, which includes: To belong to grouping setting, use group time period and user time period. Enter this menu to check certain user’s Access Options status.
  • Page 57 4. Device Settings User Acc Opts ▲ Enroll ID: 00001 Press OK to enter Option menu of Use group time period. Press “Up” and “Down” keys and select Yes. User 00001 is effective in time periods of 1, 8 and 48. “Allow Group” is set as “Yes”, we suppose that the Group 1 verifying type is password (can set it under GroupVerType of Access Control Option).
  • Page 58 ZKTECO White LCD Serials User Manual Press OK to enter. If serial number of user time period is 1 or 20, then Use group time period automatically change to “No”. GroupVerType is set as NO, so user use type (individual Verifying type) as the following figure.
  • Page 59 4. Device Settings Unlocking combination definition is to define different unlocking combinations, and each combination is composed of different groups. Unlocking combination directly uses group number and does not consider user verification sequence between each group. For example “123” represents group 1, group 2, group 3 and at least one user in each group congregates and passes verification together, then door can be unlocked.
  • Page 60 ZKTECO White LCD Serials User Manual defaults that group 1 is unlocking combination 1 and others are null. If do not want to allow all users to unlock door, then set 10 unlocking combination all to null. If only want to allow some groups to unlock door together, then set these groups in unlocking combination definition.
  • Page 61 4. Device Settings scene and the time period is effective in which at least one user in each group pass the verification together, then door can be unlocked. Combination 4: when personnel of group 4 and group 5 are all on the scene and the time period is effective in which at least one user in each group pass the verification together, then door can be unlocked.
  • Page 62 ZKTECO White LCD Serials User Manual “Group 1” and press OK to enter edit status. Press digit keys to enter 245. Then press ESC to exit and save setting interface. Note: When combination 245 is defined, then user cannot define 24, 25, and 45 as combination.

  • Page 63: Duress Options

    4. Device Settings 4.5.3.7 Door Sensor Mode DSen.Mode includes three options: No, NC, None. No: Not use door sensor. NC: When the door is open, the lock is open. None: When the door is closed, the lock is closed. Press Menu enter main interface; Select “Options”, press OK enter menu;...
  • Page 64 ZKTECO White LCD Serials User Manual Press OK, select option, and press “Up” or “Down” key to change the condition of Dsen.Alarm. 4.5.4 Duress Options Press Menu key to enter main interface. Choose “Option”, Press OK key to enter the Option Menu.
  • Page 65 4. Device Settings 1. Newly enroll duress fingerprint: Enroll new fingerprint as the duress fingerprint. 2. Define the duress fingerprint: Change the enrolled fingerprint to the duress fingerprint. 3. Cancel the duress fingerprint: Cancel the single duress fingerprint. 4. Cancel all: Cancel all duress fingerprints. 4.5.4.2 Help Key Enter the duress alarm option, press up or down key to scroll, choose the “help key”.

  • Page 66: Alarm Count

    ZKTECO White LCD Serials User Manual Duress Option Duress FP Help Key 1: 1 Trig 1: n Trig PWD Trig Alarm delay 4.5.4.4 Alarm Delay Defining automated alarm time: When the duress alarm happens and the system do not directly trigger alarm signal immediately, but can define a period time until automatically trigger alarm signal (0-255 seconds).

  • Page 67: Group Verification

    4. Device Settings the screen to select Alarm Cnt. Press OK and Input the value you want, the system provides with 0-9 digit to select, 0 means this function is invalid. Press OK key, and exit. 4.5.6 Group Verification ★ This option also is an optional item.
  • Page 68 ZKTECO White LCD Serials User Manual Auto Test ▼ ►Run all test LCD test Voice Test FP Reader Key Test RTC Test MP3 Test HID AutoTest In the option, you can run system device test. When the device broken down, it can analyze the cause of the device’s fault and the devices were quickly and easily maintained.
  • Page 69 4. Device Settings works normally. Press OK to start time and then press OK to stop time. Press ESC to exit. HID AutoTest: Test the format of HID card that user used. Note: If the device can not test the HID card number, please contact with our market support or salesmen.

  • Page 70: Voice Setting

    5. Voice Setting 5. Voice Setting 5.1 Setting through Device Enter the voice setting interface, as the following figure: Voice Setting Spd (0-10) SMS Voice Start Voice Enroll Voice Record Alarm Key Voice TellTime Menu Voice Verify Voice Set TZ Voice Set DL Voice Set UD Voice Set Recover Set...
  • Page 71 5. Voice Setting 5. Record Alarm: When the free record space exceeds the device capacity, the device will play the alarm voice after user verification. 6. Key Voice: Play the key number after user press the corresponding key. 7. Tell Time: The device will tell the current time when the time arrives every whole hour.
  • Page 72 ZKTECO White LCD Serials User Manual TZ Name Input the TZ name Morning via T9 input method Set the greeting voice via TZ Set HH:MM 07:00 T9 input method 09:00 Greet Set the begin and end time Note: User can define multiple time zones, but they can not overlap with each other.

  • Page 73: Setting Through Web Server

    5. Voice Setting 5.2 Setting through Web Server Input the device IP address in the browser, such as http://192.168.1.115, press Enter and start the login interface. The user name is admin, and the password is 0. The user name can not be modified, but the password can be modified (Enter the device Menu ->...

  • Page 74: Usb Disk Management

    6. USB Disk Management ★ 6. USB Disk Management ★ Choose USB flash disk management in the menu. Press OK, the following appears: Pen Drive Mng ▼ ►Download AttLog Download User Upload User Download SMS Upload SMS The USB flash disk can be used to download the attendance data, download and upload employee data, SMS.

  • Page 75: Download User Data

    6. USB Disk Management ★ 4) Press ESC key to exit initial interface, take out U flash disk, the files X_attlog.dat (attendance log), X_oplog.dat (management log), and X_user will be saved in the USB flash disk (X is a symbol of device number).

  • Page 76: Upload Sms

    ZKTECO White LCD Serials User Manual 6.5 Upload SMS ★ After set Short Message where is under the software, “External program”-> “Short message”. Select “External program”-> “U flash disk management”-> “Export Short Message”-> “Export SMS to U flash disk”, after export SMS successfully. Plug the U flash disk into fingerprint device.

  • Page 77: System Information

    7. System Information 7. System Information Through system Information you can view device all information, Access Menu to Sys Info, press OK, the following appears: Sys Info ▼ ►User Cnt FP Cnt Att Log 8046 Admin Cnt Pwd User Super Logs Free Space Inf Dev Info The follow table illustrates what LCD showing item means...
  • Page 78 ZKTECO White LCD Serials User Manual  Serial Num: Manufacture serial number.  Manu time: Manufacture time.  S Logs: Supper administrator’s logs.  Vendor: This device’s manufacture  Device Name: This device’s name. - 72 -...

  • Page 79: Relieve Alarm

    8. Relieve Alarm ★ 8. Relieve Alarm ★ If there is no alarm, user can not see this option. When the alarm is triggered, the option of Relieve Alarm will display on the screen, press this option will relieve the alarm. Note: The Relieve Alarm option is only available when the alarm occurs.

  • Page 80: Inquiry Records

    9. Inquiry Records ★ 9. Inquiry Records ★ This device gains a new function to inquire the record, which provides a capability to query individual or all Time & Attendance record on the device. 1. The way of inquiring attendance record This device provide user with two inquiring way: ...
  • Page 81 9. Inquiry Records ★ The attendance record display according to record time from newly to old, while brows the record, user can use the following key to operate: Function explain ▲ Display the previous content ▼ Display the next content Move a rank to left for displaying content Move a rank to right for displaying content Restore right or left displaying position to the initial...
  • Page 82 ZKTECO White LCD Serials User Manual Alter the fonts/small font’s record displaying mode, like 00014 2006-5 1/23 27 08:30 12:10 13:20 right figure, take 18:08 26 08:46 12:15 13:25 individual attendance interface 18:23 18:55 22:20 as an example, the effect...

  • Page 83: Device Maintenance

    10. Device Maintenance 10. Device Maintenance Note: Do not attempt to service the device yourself unless you are a trained service technician. Always follow the instruction closely. 1. Cleaning From time to time, the surface of optical sensor, the keypad and display window will be required to clean.
  • Page 84 ZKTECO White LCD Serials User Manual (3) Using a non-abrasive and soft, dry clothe. Be careful not to scratch the surface of the sensor. If there are lint particles here in the sensor surface, below them off when the sensor is dry.

  • Page 85: Troubleshooting

    11. Troubleshooting 11. Troubleshooting Q: Some users’ fingerprints sometimes can’t be verified. A: Cause: The following circumstances result in the staff failed to use fingerprint for verification. The fingerprint quality is poor. 1) Some fingers the fingerprint is smooth by rub-down. 2) On the finger the drape are too many, frequently change.
  • Page 86 ZKTECO White LCD Serials User Manual Q: After the fingerprint device is power on, the LCD show incompletely, only half screen, sometimes jumbled, what happens, how should solve? A: The possible reason is 1) Motherboard is bad; 2) Caused by Liquid crystal internal matter. By now need to contact supplier, and return it for repair.
  • Page 87 11. Troubleshooting You can use scotch tape to exhibit the dirt. 2) You need to contact the suppler and ask for repair. Q: When the terminal management carries on the operation, download fingerprint and the password data all successfully, but when inquiring attendance record the system prompts the failure or false, how to solve it? A: This kind of situation is possible relative with the data line, either...

  • Page 88: Appendix

    12. Appendix 12. Appendix The functions introduced in the appendix are all optional. If your device needs these functions, please consult our commercial representative or the pre-sale technical supporter. 1. USB Host Fingerprint device may be used as USB host to exchange data with external U-disk.

  • Page 89: Status Key

    12. Appendix Status Key When the attendance device under using, the different state corresponds to the different event, according to different situation a job state will be divided into: clock in, clock out, overtime check-in, overtime check out, going out, return in and so on. For the access control device in out condition is divided into “comes in”...

  • Page 90: External Fingerprint Sensor

    ZKTECO White LCD Serials User Manual the duration of ringing achieve assigned time, the ring will stop automatically. There are two ways to ring bell: 1. Send sound from the speaker of fingerprint device. 2. Connect the electrical bell to the fingerprint device, when arrive the...
  • Page 91 12. Appendix remote connection without network area, some type device support using PPP connection, PPP connection is a point to point connection through a line, PC does not dial up and connect network through modem until the fingerprint device connect with Modem and telephone, then dial up, then successfully achieve connection network.
  • Page 92 ZKTECO White LCD Serials User Manual 2) Select “create a new connection”, enter the Connection Wizard. 3) Click on the "next” in the interface as follows: 4) Select the marked item, and then click "next" in the interface. - 86 -...
  • Page 93 12. Appendix 5) Select a dial-up connection, and then click the "next". 6) Input the company name and then click "next" in the interface as follows. 7) In a telephone number column, fill the number of telephone that modems connected with, there are several situations. Via the internal extensions call the extension: Directly input the numbers of extensions that modem connect to, such as the above figure the 1019 is the numbers of extension.
  • Page 94 ZKTECO White LCD Serials User Manual number for external call number, statistics generally is 0 or 9, then enter the telephone number to call, the middle with a comma, for example, enter "9, 02150814442" on the outside can be allocated.

  • Page 95: Gprs

    12. Appendix 192.168.1.133, user terminal IP address is 192.168.1.100. GPRS General Packet Radio Services (GPRS) is a packet-based wireless communication service that promises data rates from 56 to 114 Kbps and continuous connection to the Internet for mobile phone and computer users.
  • Page 96 ZKTECO White LCD Serials User Manual specification under which a WiFi network operates is called the "flavor" of the network. WiFi has gained acceptance in many businesses, agencies, schools, and homes as an alternative to a wired LAN. Many airports, hotels, and fast-food facilities offer public access to WiFi networks.
  • Page 97 12. Appendix Step 1: Wireless End has two options: Active, Disable. If you select the Active item, you can configure the AP (Access Point). If you select the Disable, you can set the connection way of the device, and its configuration of IP address.
  • Page 98 ZKTECO White LCD Serials User Manual Ad-hoc Model, click the drop-down box to select the wireless network model, depending on the different topology of network. The Infrastructure Model will apply to Hub and Spoke wireless network, it include five Authentication Type that are OPEN, SHARED, WEPAUTO, WPAPSK, WPA2PS.

  • Page 99: Query Function

    12. Appendix If you selectRS232, must configure these parameter, Device ID, COM Port, Baud rate same with one in the communication option of the device. Configure the wireless Network IP address: (1) Click [ConfigDevice] button, the following menu pops up: (2) Select Config IP Address option, after input IP Address, click the Subnet Mask input box, and the Subnet Mask will automatically display according to IP Address.

  • Page 100: Print Function

    ZKTECO White LCD Serials User Manual complete to install T& A software, connect with device, and download attendance record. The query function provides staff with convenience to know attendance record by him. This device can not only to view personnel’s attendance record, but also support to query all staff’s record.
  • Page 101 12. Appendix [Connection] In the fingerprint device menu, the Menu -> Option -> System Option -> Advanced Settings -> Print format. There are total 10 kinds of formats available. For example: Sam punched the card at 13:24:55 on November 1, 2007, there are different print formats to select, shown as below: Version 1 00001 07-11-01 13:24:55...

  • Page 102: Mp3 Function Introduction

    ZKTECO White LCD Serials User Manual 00001 07-11-01 15:24:55 Note: 1. Be sure that the fingerprint device and the printer (super terminal) have the same baud rate. 2. If the default print format can not meet your needs, contact our...
  • Page 103 12. Appendix 1. It is need to set the period of time as the 24 hour format. 2. The 1 period of time against 1.mp3 file, the 2 period of time against 2.mp3. Such - and - such as it do. 3.
  • Page 104 ZKTECO White LCD Serials User Manual Note: xxx.xxx.xxx.xxx is an IP address of the computer to install Web server, the y is the order of mp3 file. Third step, when arrive at the playing period of time, the device will read MP3 file via Web server to play.

  • Page 105: Short Message Management

    12. Appendix Short Message Management Some of our products provide a function which can send a message to assigned person through public or person way. We only need use the background software to set it, and then upload it to the fingerprint device.

  • Page 106: Multi-Combination Authentication Mode

    ZKTECO White LCD Serials User Manual 2. Through Time & Attendance software “external program”-> “short message management” complete to set short message, choose “external program” -> “U flash disk manage” -> “export short message” -> “export to U disk”, after exporting successfully, plug the U disk into the fingerprint device, press Menu key of the fingerprint device: Pendri Mng ->...
  • Page 107 12. Appendix desire, “/” is or, “&” is and, “←” is confirm (OK). These symbols illustrate what follow the table different means. If fingerprint or Password has been used to enroll user, the verification procedure is follow: Type What you do Only verify the fingerprint 1) PIN+FP (1: 1 Verification) 2) FP (1: N Verification)
  • Page 108 ZKTECO White LCD Serials User Manual 1) RF 2) PIN+”←”+PW FP/PW/RF Verify the Fingerprint or RF or Password 1) PIN+FP (1:1) 2) FP (1:N) 3) PIN+PW 4) RF FP&PIN Verify the Fingerprint and PIN 1) PIN+”←”+FP (1:1) 2) RF+ PIN+”←”+FP (1:1) FP&PW...

  • Page 109: Card Support

    12. Appendix 1) PIN+”←”+PW+FP (1:1) 2) RF+ PIN+”←”+PW+FP (1:1) FP & PIN /RF Verify the Fingerprint and PIN, or fingerprint and RF 1) FP+ PIN 2) FP +RF 3) PIN+FP (1:1) + PIN 4) PIN+FP (1:1) +RF Note: 1) 1: N Verification mode include the 1: H, 1: G Verification. 2) In the multi-combination Verification, it is better to use fingerprint and password to enroll.

  • Page 110: Anti-Pass Back Function

    ZKTECO White LCD Serials User Manual is 13.56 MHz. Anti-pass back Function Sometimes, some illegal person follows the employee into the gate, which will bring security problem. To prevent such risk, this function is enabled. In record must match out record, or the gate won’t be open.
  • Page 111 12. Appendix When master machine is set as “out anti-pass back”, if user wants to come in and go out normally, his recent record must be “in”, or he cannot go out. Any “out” record will be refused by “anti-pass back”. For example, a user’s recent record is “in”, his second record can be “out”...
  • Page 112 ZKTECO White LCD Serials User Manual Device status There are three options: Control-in, control-out and none Control-in: When it is set, the verified record on the device is in-record. Control-out: When it is set, the verified record on the device is out-record.

  • Page 113: Remote Server Solution

    12. Appendix Remote Server Solution Because of the limit of standalone device capacity and speed, there is impossibility to add a large mount of fingerprints (for example, up to ten thousands of fingerprints). Even if the capacity can be expanded, the standalone device speed can’t be assured;...
  • Page 114 ZKTECO White LCD Serials User Manual The basic mode adopts C/S mode, please see the following figure Prim-Server Central database and Server PC_server PC_server Sec-Serv Server Terminal Assign a primary server by logic partition acts as central database. In some large applications, a special server can be selected to make sure...

  • Page 115: Iclock Time & Attendance

    12. Appendix 2. Matching fingerprint information passed by third level server. Third level server: 1. The fingerprint information will be got in the time of fingerprint press. 2. Keyboard input. For more detail please contact us to get technical assistance. iClock Time &...

  • Page 116: Web Server Access Control

    ZKTECO White LCD Serials User Manual Thought TCP/IP and Ethernet, WEB Server is able to reliable apply to local network, the data fingerprint device store up can be watch and deal via long distance network, with browser it is not need to administrator or...

  • Page 117: Collect Ip Address Automatically

    12. Appendix Architecture, use WEB page request to process and manage date, in addition the Web Sever Access Control solution is independent on regional limit, permits downloading and remote on-line management the fingerprint terminal through IE or Netscape browser, handle time sheet corrections and create report table , its go far beyond traditional Access Control Software, It also incorporates the many years of experience of the team.

  • Page 118: About Wiegand

    ZKTECO White LCD Serials User Manual About Wiegand The device pursuant the Wiegand standard specified by the Security Industry Association's (SIA) Access Control Standard Protocol for the 26-Bit Wiegand Reader Interface document. Manufacturers have adopted the Wiegand standard to establish a common Wiegand interface.
  • Page 119 12. Appendix Figure: Time Wiegand format F Series Fingerprint Access Control Wiegand format is a general Access Control protocol. 26-bit Wiegand formats The composition of the open de facto industry standard 26 Bit Wiegand format contains 8 bits for the facility code field and 16 bits for the ID number field .Mathematically these 8 facility code bits allow for a total of just 256 (0 to 255) facility codes, while the 16 Id number bits allow for a total of only 65,536(0 to 65,535) individual ID’s within each...
  • Page 120 ZKTECO White LCD Serials User Manual Bit 2 is MSB ( most significant bit) Card code, (0-65,535), bit10 is MSB (most CC (bit10-bit 25) significant bit) Odd parity bit, OP is definite by over bit 13 to 26, if there are odd “1”, opposition it is 0.

  • Page 121: Soap

    12. Appendix other proximity manufacturers, Keri can normally match that format. Although the customer is primarily responsible for custom format card coding, as an added benefit Keri Systems tracks card coding for additional security. Table 4: Example of a Custom Wiegand Format Bit Number Purpose Bit 1...

  • Page 122: About Poe

    ZKTECO White LCD Serials User Manual About POE Summary Power over Ethernet (PoE) is a revolutionary technology that extends the already ultra-broad functionality of Ethernet by supplying reliable DC power over the same Category 5/5e twisted-pair cable that currently carries Ethernet data. PoE, modeled after the technology used by the...

  • Page 123: Backup Battery

    12. Appendix wires to each network device. WAPs and security cameras can be installed without the additional expense of contracting an electrician to install AC outlets where deployed. PoE also helps protect IT investments as it is forward and backward compatible with other Ethernet protocols.
  • Page 124 ZKTECO White LCD Serials User Manual supply with directly current that is translated form alternating current by adopter, if the reserve battery is in non-saturation state, it will charge up automatically. When the power cut down, the reserve battery will switch into discharge state to power on fingerprint device.

  • Page 125: Digits Code

    12. Appendix 3. Please use original charger only. 4. DO NOT inverse polarity connection. 5. DO NOT plug the batteries directly into the outlet or the cigarette receptacle of a car without inserting a proper charger between the batteries and the outlet or the receptacle. 6.

  • Page 126: Daylight Saving Time

    ZKTECO White LCD Serials User Manual fingerprint device as the Server of corporate network, it is need to set the option of automatically Synchronized Time in fingerprint device that want to be calibrate time as time Server IP address , modify the IP address of time client to connect with time server.
  • Page 127 12. Appendix example after the fingerprint authenticate is positive, the fingerprint device say “ thanking you!”, if the fingerprint authenticate is negative, the device will prompt “ please put fingerprint again !”. In order to get more satisfy human nature request and bring into play voice function, we provide with assign time to play voice that design for carrying on assigned operation depending on different need and send different voice prompt contents, e.g.

  • Page 128: Work Code

    ZKTECO White LCD Serials User Manual 2. After completing setting, be sure to restart device, so configuration take effect. Note: If you want more detail, please contact our technical Assistance. Work Code We offer the concept about work code that depend on the result of...

  • Page 129: Dhcp

    12. Appendix Work code, user may go to advance development. According to the different category to deal with it, thereby it will realize statistic different type of work and way of verification. Note: 1) If the test is not passed directly enter any figures on the OK button, the code marker 0.

  • Page 130: User Grouping

    ZKTECO White LCD Serials User Manual apply to our fingerprint device, when the fingerprint device is connected into network as DHCP client, which will broadcast a message for all local network, after the DHCP sever receive the request and assign a dynamic IP address and DNS according the actual statue in the network.

  • Page 131: T9 Input Method

    12. Appendix New Enroll Input Group ID Note: The current group ID is the default value. If you need to modify it, input the value you wanted. Group Verification Method: If you set “Allow Group” to Yes, set the verify mode to Group, that is, assign a user to a group, when the user need to verify, he need to input the group ID first, and then press the finger.

  • Page 132: Tts Function

    ZKTECO White LCD Serials User Manual device, for example the numeric keyboard 1 has the A, B, the C three letters, only input key where this letter locate for the T9 input, the program automatically display this key expressed all letters, press the ▲/▼...
  • Page 133 12. Appendix playback of voice possible, voice tonality and smooth. That make the listener feel natural and feel no jerky sense of indifference. The user can modify it through the PC software as needed personalized voice prompts. Operation of specific equipment, please refer to 5.

  • Page 134: About The Human Rights Privacy Statement

    12. Appendix About the Human Rights Privacy Statement Dear customer: First thank you for using fingerprint identification product we design and produce. As one of the global famous fingerprint identification core technology provider, we are unceasingly carrying on the development and research, also we believe such action is necessary to: (a) comply with the law or legal process served on Our company;...
  • Page 135 12. Appendix provider as the equipment original producer, we have not any legal liability for any damage it cause. Note: There are limited rights to privacy and human rights in the Chinese Constitution. The personal dignity of citizens of the People's Republic of China is inviolable and further, that insult, libel, false accusation or false incrimination directed against citizens by any means is prohibited, the protection of freedom of the person and the residence .The Constitution...

  • Page 136: Environmental Protection

    12. Appendix Environmental Protection The environmental protection use period marked on our products is the safety period of our products used under the conditions specified by this manual without toxic and harmful substances leaking happened The environmental protection use period marked on our products does not include the easy wear and tear components required to be replaced regularly such as the battery etc.

Table of Contents
