5.2. Option Black Box Preamp
Connecting to the amplifier
► Please observe the safety instructions and positioning information (see page 1).
1. Before connecting the unit, make sure that the Phono Module is switched off via its
on/off switch or disconnect the plug from the wall outlet.
2. When inserting the connector, guide the anti-rotation lug carefully into the mating recess in
the socket.
3. Switch on the amplifier. The LED on the front panel of the unit will illuminate.
4. Should you wish to disconnect the Black Box Preamp, switch the amplifier off first and wait
until the LED on the front panel has gone out.
Technical data
General Data
170 x 98 x 257 mm
Dimensions
(Width x Height x Depth) with cable clamp and angled cable
Weight 3.3 kg
Cable length 1 m with connector. Longer lengths are available upon request
See separate operating instructions "Input and output modules". in the cover sheet of this instruction
manual.
The modular structure of the new phono module enables a multitude of possibilities on both the input
and output side, which leave nothing to be desired for both phono and high-level listeners. Different
line and phono input modules are available up to the step-up transformer and 3 output modules. The
output modules are unique and also allow direct connection to a power amplifier.
5. OPTIONS
6. IN- AND OUTPUTS
