4.7. Subsonic Filter

Frequency Response of the Phono Module ( RIAA Curve ) with and without Subsonic Filter:

Low Frequency Signals below 20 Hz will be reduced through the Subsonic Filter by 12 dB /

Octave. Acoustical feedback from the speaker to the cartridge is also eliminated (this effect

occurs with speakers having an extended range in the bass).

4. MAIN UNIT

Flat Graph, Fre-

quency Response

without Subsonic

Filter

Descending

Graph, Frequency

Response with

Subsonic Filter
