HANGE YSTEM Dear Customer, Congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for the highest precision, top quality and best service. You are going to increase the process reliability of your production and achieve best machining results – to the customer's complete satisfaction.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Contents SAFETY ..............................3 ............................ 3 YMBOL KEY .......................... 3 PPROPRIATE ................. 3 NVIRONMENTAL AND OPERATING CONDITIONS ..........................4...
Please make sure that your application has been checked based on the current SCHUNK calculation program. If this is not the case, we can provide no warranty. Requirement for quality of the compressed air according to ISO 8573-1: 6 4 4 Clean ambient conditions at room temperature are required.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 1.4 Safety Notes Caution ! The pins of the electric module can be damaged during operation! Switch off the energy transmission during coupling and decoupling.
Additional holes, threads or attachments which are not supplied as accessories by SCHUNK may only be applied after obtaining the prior consent of SCHUNK. The maintenance and servicing intervals must always be complied with. The inter- vals indicated refer to a standard working environment.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Assembly and Installation 5.1 Assembly CAUTION ! Switch off the power supply during installation of the quick-change system. Comply with the safety instructions in Chapter 1.3, page 3.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 5.2 Example of mounting An interface plate with a hole pattern for mounting holes is available optionally. The adapter plate is bolted to the robot and the quick-change head (data for mounting and mounting bolts can be found in our catalog).
Assembly and Operating Manual Quick-Change-System type SWS-I-011 5.3 Installation The connection dimensions can be found in the respective drawings in the current catalog or in our CAD data service on the Internet (link under www.schunk.com). Air connection 5.3.1 CAUTION! Switch off the power supply during installation of the quick-change system.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Electrical connection 5.3.2 CAUTION ! Switch off the power supply during installation of the quick-change system. Comply with the safety instructions in Chapter 1.3, page 3.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Pinout of the electrical connection 5.3.3 The air feed-throughs L1, L3, L4 and L6 are switched via the valves 1, 3, 4 and 6. The valve 2 locks the quick-change system and the valve 5 unlocks the quick-change system.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Troubleshooting Malfunction Possible cause Corrective actions (1) Min. air pressure of (1) Check air supply and Quick-change head 3.5 bar exceeded...
Page 12
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Figure 6: Loosen set screw to unlock Date printed 28.02.11...
(2) Service the quick-change system SWS-I according to Table 6: Maintenance intervals . At every maintenance work the sealing have to be exchanged. (The complete seal kit can be ordered from SCHUNK. For Id.-No. of the seals, see chapter 11.1 page 21).
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Disassembly of the Quick-Change-Heads SWK-I-011 CAUTION ! Please observe chapter 7 page 13 as well as the safety information on page 3.
Quick-Change-System type SWS-I-011 Programming aid To simplify the teach process and programming, Schunk offers a programming aid (ID no. 302814) It consists oft he tool-side module SWA-I-011(ID no. 5517913) and the robot.side module SWK-I-011 (ID no. 5517912). Both modules can be purchased separately.
Page 16
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Step 3 Lock the programming aid /33/ with the robot-side change head /31/. The marking A must be on the side oft he electric feed-through /32/.
Page 17
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Step 4 In the teach process, move the tool-side change head /27/ into position over the robot- side change head /31/.
Page 18
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Step 6 Make sure that the markings „A“ and „B“ line up with each other. Correct the position of the robot to compensate for any lateral misalignment.
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Assembly Drawing 10.1 SWS-I-011 axial output Figure 12: Exploded drawing axial output Date printed 28.02.11...
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 10.2 SWS-I-011 radial output Figure 13: exploded drawing radial output Date printed 28.02.11...
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 Bills of materials 11.1 Seal kit Seal kit (Id.-No. 5517080) Ident.-Nr. Quatity Description 9611175 O-ring 10 x 1,5 mm...
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 SWK-I-011 radial output (Id.-No. 302 811) 11.2.2 Ident.-Nr. Quatity Description Wearing part? 5516858 Quick-Change-Head 5516860 Pin retainer 2 9948368...
. c o m o s o . c o m Assembly and Operating Manual Quick-Change-System type SWS-I-011 SWK-I-011 axial output (Id.-No. 302 812) 11.2.3 Ident.-Nr. Quatity Description Wearing part? 5516858 Quick-Change-Head 5516860 Pin retainer 2 9948368...
