MIX FOLLOW: Will cause the image to mix out and remain there while the GPI signal is
LOW (0.0 to 0.4 VDC); the image will immediately mix in when the GPI signal returns high (4.0
to 5.0 VDC).
FRZ OFF: Will cause image to unfreeze when a GPI pulse is received.
FRZ ON: Will cause the image to freeze when a GPI pulse is received.
FRZ TOGGLE: Will cause the image to freeze on the first receipt of a GPI pulse; and unfreeze
on the second receipt of a GPI pulse
FRZ FOLLOW: Will cause the image to freeze and remain there while the GPI signal is LOW
(0.0 to 0.4 VDC); the image will immediately unfreeze when the GPI signal returns high (4.0 to
5.0 VDC).
SEQ BEG: Will cause the unit to display the previous START mode keyframe when a GPI
pulse is received.
SEQ REV: Will cause the unit to initiate a reverse sequence when a GPI pulse is received
SEQ STOP: Will cause the unit to halt an in-process sequence when a GPI pulse is received
SEQ FWD: Will cause the unit to initiate a forward sequence when a GPI pulse is received.
SEQ NEXT: Will cause the unit to skip to the next keyframe when a GPI pulse is received.
SEQ END: Will cause the unit to skip to the next STOP mode keyframe when a GPI pulse is
received.
SEQ FOLLOW: Will cause the unit to initiate a forward sequence from KEYFRAME 00 to the
next STOP mode keyframe and hold there while the GPI pulse is low (0.0 to 0.4 VDC); the unit
will immediately initiate a reverse sequence returning to KEYFRAME 00 when the GPI signal
returns high (4.0 to 5.0 VDC).
