5.3 Installing tooling onto a 20" Grinding Plate
This illustration below shows how to install tooling to the 2
Figure 5-3 How to install tooling to the 2
1 Align the holes in the tooling trape oid plate with the holes in the grinding plate
2 Screw three M6 1 14 screws into the grinding plate and into the tooling trape oid
holes using a 4mm Allen wrench
grinding plate
