Dynamic Diamond Tooling
4.2.7 Installing Additional Weight
4.2.7.1 Installing additional weight to the head of the machine
This illustration below shows how to install additional weight to the head of the machine
Grasp the weight with the handles and align the two holes on the bottom of the weight with
the two securing pins on the head block of the machine
The weight is fitted with magnets and will therefore snap into place and remain secure
eight Securing Holes
eight Securing ins
Figure 4-1 How to install additional weight to the head of the machine
Page 25
DDG 1220 User Manual
