DYNAMIC DIAMOND TOOLING Beast User Manual page 15

Dynamic Diamond Tooling
3.2 Machine Overview – Left Side
8
8
Figure 3-2 Machine overview – Left Side
Item Description
Throttle Control
1 Cup Holder
Handle Tilt Adjustment
2 Handle Tilt Adjustment
Handle Height Adjustment
3 Handle Height Adjustment
4 Foot Hold to Tilt Machine back
5 Grinding Head Level Adjustment Bolt
6 Grinding Head Level Indicator
7 Grinding Head
8 Transport Handle
Page 9
DDG 1220 User Manual
1
1
2
2
3
3
4
4
5
5
6
6
7
7
