4.2.7 Grinding Head Adjustment for Edging
How to adjust the grinding head left or right for edging
Follow the following steps in order to adjust the grinding head:
1 Loosen the Grinding Head Lock Bolt with a 1 mm Allen wrench
2 Turn the Grinding Head Adjustment Bolt with a 1 mm Allen wrench in the
direction ou desire to move the grinding head Screwing the Grinding Head
Adjustment Bolt
clockwise will move the grinding head L FT Screwing the Grinding Head
Adjustment
Bolt counter clockwise will move the grinding head IGHT
3 The Grinding Head Alignment Indicator shows when the grinding head in its full L FT
or IGHT position
4 Tighten the Grinding Head Lock Bolt with a 1 mm Allen wrench when
adjustment is complete
Grinding Head
Adjustment Bolt
Tilt the grinder so that the handle is resting firml on the floor with the
grinding head off the floor
NOTE: ensure that one person is securing the handle at all times when the grinder
is tilted so as to rest on its handle.
Page 21
DDG 1220 User Manual
Grinding Head
Alignment Indicator
Grinding Head Lock Bolt
