4.2.3 Head Leveling System
Description
The DDG 122 is incorporated with a Head Leveling S stem Its primar purpose is to
keep the grinding head level with the grinding surface when using a variet of tooling
The grinder is fitted with a level on the grinding head in order to show if an adjustment is
needed Leveling the grinding head is achieved b adjusting the Head Leveling
Adjustment ut until the level indicator bubble is centered
How to adjust the level of the Grinding Head
1 Fit the machine with the tooling ou desire
2 Check to see if the level indicator is indicating a level position bubble centered
3 If an adjustment is needed use the adjustment wrench included and found b the
foot hold and adjust the Head Leveling Adjustment ut so as to center the bubble
in the level indicator
