4.2 Operation of Machine
4.2.1 Dust Shroud Installation
How to install the 12" shroud
Secure 3 hose to dust port inlet on shroud
lace shroud over grinding head casing
Rubber Dust Shroud Installation
How to install the 12" rubber dust shroud
Secure rubber shroud holes onto shroud pins on shroud
ull the rubber dust shroud over the grinding head casing and secure onto shroud pins
on opposite side of shroud
Page 11
DDG 1220 User Manual
