Summary of Contents for Datavideo SE-500MU4K
- Page 1 4K 4 CHANNEL VIDEO SWITCHER SE-500MU4K Instruction Manual...
-
Page 2: Table Of Contents
Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or incorrect information. -
Page 3: Fcc Compliance Statement
AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. 8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be walked on, rolled over, or otherwise stressed. -
Page 4: Warranty
Warranty Standard Warranty Datavideo equipment are guaranteed against any manufacturing defects for one year from the date of purchase. The original purchase invoice or other documentary evidence should be supplied at the time of any request for repair under warranty. -
Page 5: Three Year Warranty
Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting, Camera module, PCIe Card are covered for 1 year. The three-year warranty must be registered on Datavideo's official website or with your local Datavideo office or one of its authorized distributors within 30 days of purchase. -
Page 6: Introduction
Introduction The Datavideo SE-500MU 4K is a 4K digital video switcher built into a 1RU chassis, supporting up to Ultra HD video formats via four 4K HDMI input with a video scaler capable of connecting different resolution sources at the same time. -
Page 7: System Diagram
System Diagram... -
Page 8: Connections And Controls
Connections and Controls In this chapter, we will describe various connection ports on the device as well as panel functions. Rear Panel HDMI Video IN 1 – 4 DVIP Port Audio Input – Stereo RCA (Left/Right) PGM OUT Upgrade / FW Upgrade HDMI Video Output (AUX/PGM) DC IN 12V TALLY Output Port... - Page 9 This port allows the SE-500MU 4K to establish direct connection with the PC or an Ethernet switch or router. 7. PGM OUT Upgrade / FW Upgrade Connects USB drive for FW upgrade. Contact your local Datavideo Office or dealer for further advice.
-
Page 10: Front Panel
8. DC IN 12V DC in socket connects the supplied 12V PSU. The connection can be secured by screwing the outer fastening ring of the DC In plug to the socket. 9. Power Switch Turns the device ON/OFF 10. Grounding Terminal When connecting this unit to any other component, make sure that it is properly grounded by connecting this terminal to an... - Page 11 3. AUX Button Press and hold the AUX button to enable the AUX output mode. Follow the steps below to select the AUX output source. 1. Press the AUX button 2. Press one of the channel buttons to select a video source. 3.
-
Page 12: Appendices
The SE-500MU 4K has a D-sub 15 pin female tally output port. These connections provide bi- colour tally information to a number of other Datavideo products, such as the ITC-100 eight channel talkback system and the TLM range of LCD Monitors. The ports are open collector ports and as such do not provide power to tally light circuits. - Page 13 Appendix 2 RS-232 Serial Port Pinout The user is allowed to connect a custom keyboard controller to the SE-500MU 4K via RS-232 interface. The table below provides the RS-232 pinout on the device end (SE-500MU 4K). Note that the RS-232 port is a 9 pin D-sub female connector. Pin No.
-
Page 14: Appendix 3 Dimensions
Appendix 3 Dimensions All measurements in millimeters (mm) -
Page 15: Appendix 4 Specifications
Appendix 4 Specifications Model Name SE-500MU 4K Product Name 4K 4 Channel HD Video Switcher Video Standard 4K, Full HD & SD 2160p 23.98/24/25/29.97/30/50/59.94/60Hz 1080p 23.98/24/25/29.97/30/50/59.94/60Hz 1080i 50/59.94/60Hz Video Format 720p 50/59.94/60Hz 576i 50Hz 480i 59.94Hz 4K2K60 4:4:4 8 bit Video Processing 4K2K60 4:2:2 10 bit Video Input... -
Page 16: Service And Support
Nov-18.2020 Version E1 Datavideo Technologies Co., Ltd. All rights reserved 2020...
