Toronto Single
Assembly Instructions -
Dimensions
Width - 96cm
length - 190cm
Height - 85cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or
missing parts, call our Customer Helpline: 01242 621266
Please k eep for future reference
697/0804
697/0770
697/0835
697/0749
Issue 2 - 31/01/2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Toronto 697/0804
Summary of Contents for Argos Toronto 697/0804
- Page 1 Toronto Single Assembly Instructions - Please k eep for future reference 697/0804 697/0770 697/0835 697/0749 Dimensions Width - 96cm length - 190cm Height - 85cm Issue 2 - 31/01/2014 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call our Customer Helpline: 01242 621266...
- Page 2 Safety and Care Advice Important–Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight • We do not components and tools listed on the product, this could recommend the on pages 2 and 3.
- Page 3 Components-Fittings If you have any damaged or missing parts, call our Customer Helpline: 01242 621266 Please check you have all the ?ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more ?ttings may be supplied than are required.
- Page 4 Components-Panels Please check you have all the panels listed below Bed Panels Side Rails x 2 (190 x 18cm) Toe End Panel x 1 (96 x 35cm) Head End Panel x 1 (96 x 49cm) Headboard Struts x 2 Headboard Rails x 2 (96 x 17cm) Roll of Slats x 1 Underbed drawer Panels...
- Page 5 Assembly Instructions Step 1 Note the correct alignment of the Fitting the side rails Cross Dowel slots to the head end panel Position the side rails as shown and fit 2 x M6 Cross dowels in to the side rails. Note that the slot must be aligned as shown in the diagram.
- Page 6 Assembly Instructions Step 3 Fitting the headboard Pilot Holes struts to the head board rails Position the headboard rails and headboard struts as shown. Fix the struts to the rails using 8 x 15mm round head screws Note that the pilot holes on the headboard rails are offset - see diagram below.
- Page 7 Assembly Instructions Step 5 Fitting the roll of slats to the side rails. Open the roll of slats and lay them on the side rails as shown. Pull the end slats out so that they touch the head end panel and the toe end panel.
- Page 8 Assembly Instructions Step 7 Fitting the castors to the support rails Position the support rails and the castors as shown. Using the round head screws fix the castors to the support rails shown. x 10 Step 8 Fitting the cam pegs to the drawer back and front.
- Page 9 Assembly Instructions Step 9 Fitting the support rails and drawer sides to the drawer front Position the drawer sides and the support rails Centre Support Rail as shown. Put a small amount of glue into the holes and gently tap the support rails Glue the dowels into the drawer front in place...
- Page 10 Assembly Instructions Step 11 Fitting the handles to the drawer front Position the drawer as shown. Use 2 x screw to fix the silver handle to the drawer front as shown. Step 12 Finally push the drawer unit under the bed frame. The bed is now complete.
