   Summary of Contents for Nokia Mediamaster 230 S

  • Page 1

    User Guide...

  • Page 2

    Mediamaster 230 S, è conforme ai requisisti fondamentali e alle disposizioni della Direttiva 1999/5/ Με το παρόν, η Nokia δηλώνει ότι ο παρών ψηφιακός δέκτης, Mediamaster 230 S, συµµορφώνεται µε τις βασικές απαιτήσεις και τις σχετικές διατάξεις της οδηγίας 1999/5/ Nokia toteaa, että...

  • Page 3: Quick Guide

    Satellite dish The satellite dish must have a clear view to the satellites. Mount the satellite dish according to the fitting instructions. In case you already have a satellite dish mounted, note that you need a Universal LNB which works on the frequencies 10.70- 12.75 GHz to be able to handle digital signals.

  • Page 4

    One antenna/one LNB configuration Select this alternative if you have one (1) LNB mounted on the an- tenna. • Press opt to view the predefined channel. LNB type Select the correct LNB type for your configuration. The most com- mon values, including Universal LNB, are selectable with the cur- sor left and cursor right buttons.

  • Page 5: Table Of Contents

    Nokia operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products described in this manual without any prior notice.

  • Page 6

    Nokia Corporation, Nokia Home Communications (“Nokia”). The Agreement authorizes You to use the Software specified in Clause 1 below and which is included in this Nokia digital TV receiver. This is an agreement on end-user rights and not an agreement concerning sale.

  • Page 7

    Nokia. Your end-user rights automatically and immediately terminate without notice from Nokia if You fail to comply with any provision of this Agreement. In such an event, You must immediately return at Your own cost, this Nokia digital TV receiver, and all related material to the place of purchase.

  • Page 8: General Information

    • Do not allow the unit to be exposed to hot, cold or humid conditions. • Service should be carried out only at a Nokia Authorised Service Centre. • Please note that the only way to isolate the Mediamaster completely from the...

  • Page 9: Remote Control

    Remote control This section describes how to operate the Mediamaster using the buttons on the remote control. The standby button has double functions. One function is carried out if you press the button gently once and the other function is carried out if you hold down the button for a few seconds. Some of the functions can also be carried out using the buttons on the front panel.

  • Page 10: Front And Rear Panel

    Front and rear panels Front panel Slot for a CA module with a smart card Button push the button to release a CA mod- ule that has been inserted. Function Standby Locked to channel Remote control feedback SW download Error Bluetooth function turned on Bluetooth function turned off Rear panel...

  • Page 11: About The Smartcard And Ca Module, General, The Right-hand Card Slot

    Service Provider. Note: CA modules and smart cards are only distributed by Serv- ice Providers and special distributors, not by Nokia. After inserting a card, leave it in the slot permanently. Do not re- move it again, unless you are asked to do so. This is important, for example, if your Service Provider wants to download new in- formation to the smart card, as the card has to be in the slot.

  • Page 12: Installation Of The Mediamaster, Preparing The Remote Control, Connecting The Mediamaster To The Dish, General

    Installation of the Mediamaster The Mediamaster box should contain the following items: • the Mediamaster • a remote control with 2 AAA batteries • a SCART cable (fully connected 1.0 metre) • a mains cable • an owner’s manual with the software license agreement About the SCART sockets The rear panel of the Mediamaster contains 2 SCART sockets (see diagram).

  • Page 13: Connecting To The Tv, Connecting A Tv And Vcr

    • Connect the TV aerial to the RF input socket on the analogue receiver. In order to switch the signal from the dish between the ana- logue and digital receivers, you will need a Nokia smart switch (at A B in the diagram) or a Universal Twin LNB. Nokia smart switch •...

  • Page 14: Connecting A Hifi System

    Installation of the Mediamaster Connecting a Hi-fi system • Connect an RCA stereo cable from the AUDIO L R sockets on the Mediamaster to the LINE, AUX, SPARE or EXTRA input sockets on your Hi-fi system. • If available, you can connect a single RCA cable from the DIG- ITAL AUDIO socket on the Mediamaster to a Hi-fi system that is equipped with digital audio input.

  • Page 15: First-time Installation, General Information, The "first-time Installation" Menu, Language, Antenna/satellite Selection

    First-time installation General information Once you have correctly connected the Mediamaster, you will also have to perform a “First-time installation.” During this pro- cedure, helpful information is displayed at the bottom of the menus. Please note! The select button always confirms a selection within these menus, and pressing it will take you to the next step in the instal- lation process.

  • Page 16: One Antenna/one Lnb Configuration, Multisatellite/diseqc Switch Configuration

    First-time installation One antenna/one LNB configuration Select this alternative if you have one (1) LNB mounted on the antenna. • Press opt to view the predefined channel. LNB type Select the correct LNB for your configuration. The most common values, including Universal LNB, can be selected using the cur- sor left/cursor right button.

  • Page 17

    First-time installation Typical connection of a two-way DiSEqC switch: • Connect the cable from the LNB that is intended for channels from the ASTRA satellite (or THOR) to the connector marked LNB 1 (A) on the switch. • Connect the cable from the HOTBIRD satellite (or SIRIUS) to the connector marked LNB 2 (B).

  • Page 18: Motor Antenna Configuration

    • From the “Antenna/Satellite selection” menu select option 3 “Motor Antenna Configuration” and press select. Type of motor • Select SATSCAN (ASTRA) if you have a Nokia SatScan motor. • Select DiSEqC (Hotbird) if the motor that you have is control- led by DiSEqC commands.

  • Page 19: Channel Search

    First-time installation Remove limits If you need to remove the limits. When you activate this command, the motor will turn itself to the 0° (Zero) position. However, the next time you select a channel, the motor will turn to its proper position. Channel search The Channel search procedure can be carried out in different ways.

  • Page 20: Channel Search In Progress, Time Adjustment

    First-time installation Advanced manual search The information that must be entered in this menu is available in satellite TV magazines or on the Internet. You can use this menu if you are looking for some “special” chan- nels (i.e. non-DVB standard channels) which can only be found when you have entered the necessary settings here.

  • Page 21: Navibars, General Information, The "control" And The "settings" Folders

    NaviBars General information • Press select to open the NaviBars. The NaviBars is used for selecting TV/Radio channels and chang- ing system settings. The horizontal row contains folders, for example, All TV, Set- tings and so on. Their names are shown in black text at the bot- tom of each folder.

  • Page 22

    NaviBars ☛ Control folder User preferences Banner time-out When you switch channels, an information banner will be shown for a few seconds. You can select the length of time that the banner will be shown. Volume bar Select whether or not you want the volume bar to appear on the screen when you change the volume.

  • Page 23

    NaviBars Important information about editing channels Before you start, you must select the list, TV or radio, that you want to edit. If you are watching TV and press select and choose Edit channels, you can only edit TV channels. If you are listening to radio channels you can only edit radio channels.

  • Page 24

    NaviBars Delete list If you want to delete a Favourite list, select the list using the cur- sor left/cursor right button and press select. Rename list You can give an existing list a new name by following the instruc- tions in the “How to give a specific name” section on page 19. Rearrange lists If you have created several Favourite lists, you can determine the sequence in which the lists will appear.

  • Page 25

    NaviBars Lock channels To open this menu, you will be asked to enter your access code. The access code is set to 1234 at the factory. You can lock (and later unlock) channels on any of the lists in or- der to prevent, for example, your children from watching.

  • Page 26

    NaviBars • You can adjust the dish using channel preview if PID informa- tion has been entered. • Press select to start the channel search. • When you get the message on the screen that ”you have found X new TV-channels and X new radio channels”, press select to save the new channels.

  • Page 27

    NaviBars Viewing images received from an external device General 230 S is equipped with a built in Bluetooth module that makes it possible to receive, watch and also save digital images trans- mitted from an external device. This device must be equipped with the Bluetooth Standard Version 1.1 and “Object Push Pro- file”.

  • Page 28

    NaviBars Local device name The 230 S is named Mediamaster on this line. This is also the name the external device will find during its search procedure. You can enter another name with the number buttons on the remote control. Press any number button and a keyboard will be shown on the screen.

  • Page 29

    NaviBars ☛ Control folder Timer General You can program the Mediamaster to switch on and off at predefined times. The timer function is very useful when you want to record a pro- gramme and you are unable to start/stop the recording event yourself, or when you just want to be reminded of the start of a programme that you do not want to miss.

  • Page 30

    Time Installation. Please refer to page 19. Update channels via a PC On the Nokia web site (www.nokia.com) you can download a Windows™ software for updating the channel lists via the serial port. The serial port connector can be found on the back of the Mediamaster (see page 10) .

  • Page 31

    NaviBars Picture format If you have a TV set with a 4:3 picture format and the transmis- sion is 16:9, you can select “Fullscreen” or “Letterbox”. Fullscreen will fill the screen but some information on the left and right sides will be cut off. Letterbox will give a complete picture, but black areas will be vis- ible at the top and bottom of the screen.

  • Page 32: Games Folder

    This will damage the software and the receiver will have to be sent for a service! Please check for the latest updates for your receiver at Nokia’s website www.nokia.com. ☛...

  • Page 33: Viewing Mode, General Information, Programme Information

    Viewing Mode General information The following describes the basic functions of your Mediamaster that can be used while watching satellite TV or listening to sat- ellite radio. Some of the functions described here are dependent on the Service Provider and can only be used if they are included in the transmitted programme information.

  • Page 34: Extended Programme Information

    Viewing Mode Extended programme information The Mediamaster can display information about programmes that are currently being broadcasted as well as those that will be broadcast next. This procedure is the same for both TV and radio mode. By pressing info while watching TV the “Programme informa- tion”...

  • Page 35: Tv Release (0), Teletext

    Viewing Mode TV release (0) With the 0 button you can toggle between analogue terrestrial TV, video, and analogue and digital satellite TV signals. Teletext Pressing txt will open a teletext page (if teletext is transmitted on that channel.) Select teletext pages using the numeric buttons on the remote control.

  • Page 36: Glossary Of Terms

    Glossary of terms AC-3 A multichannel digital audio encoding system. Access control A feature that allows parents to ”lock” programmes that they consider to be unsuitable for children. A ”locked” channel or programme can only be ”unlocked” using the special access code. Access code A four-digit code stored in the Mediamaster.

  • Page 37: Troubleshooting

    Troubleshooting Problem The LED on the front panel does not light up/is not lit. The left-hand LED is red No sound or picture. No sound or picture on the horizon- tal modulated transponder. Bad picture/blocking error. There is no Welcome menu on the screen after you have switched the Mediamaster on for the first time.

  • Page 38: Technical Specifications

    Technical specifications Transmission standards DVB, MPEG 2 LNB/Tuner input Connector 1x F-type (LNB) RF input frequency 950-2150 MHz QPSK Ku & C-band SCPC & MCPC RF input power level -20 to -65 dBm Supply voltage 13/18 V ± 5% Max. current 500 mA, overload protected Control voltage 22 kHz, 0.65 V...

  • Page 39: Menu Screen Structure

    Menu screen structure First time installation Language preferences “First-time English Deutsch One antenna/One LNB configuration installation” Français Espanol Multisatellite/DiSEqC Switch menu Italiano Nederlands configuration Motor antenna configuration NaviBars System information Hardware version System software Boot software version Timer setup Timer list Channel list __/__/__ -:- -:- _______ Channel...

  • Page 40

    Nokia is a registered trademark of Nokia Corporation www.nokia.com 00000365.00...
