Nokia mediamaster 310 s digital receiver user guide.
Hide thumbs

Advertising

Advertising

User Guide

Advertising

   Summary of Contents for Nokia Mediamaster 310 S

  • Page 1

    User Guide...

  • Page 2

    (Dual Tone Multiple Frequency). Nokia intygar härmed att denna digitala mottagare, Mediamaster 310 S, uppfyller kraven enligt direktiv Nokia declara que el receptor digital Mediamaster 310 S 1999/5/EC. cumple con los requisitos básicos de conformidad y con Denna mottagare kan anslutas till ett analogt telefonnät...

  • Page 3: Quick Guide

    Quick guide Satellite dish The satellite dish must have a clear view to the satellites. Mount the satellite dish according to the fitting instructions. In case you already have a satellite dish mounted, note that you need a Universal LNB which works on the frequencies 10.70-12.75 GHz to be able to handle digital signals.

  • Page 4

    Quick guide Antenna type selection This Quick guide only describes a setting combination with one antenna with an LNB directed towards one satellite. ☛ • When this is the case, select the first line One LNB and press ok to continue. •...

  • Page 5: Table Of Contents, Nokia Mediamaster Software

    Nokia operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products described in this manual without any prior notice.

  • Page 6: End-user License, Nokia Mediamaster Software

    Nokia Corporation, Nokia Home Communications (“Nokia”). The Agreement authorises You to use the Software specified in Clause 1 below and which is included in this Nokia digital TV receiver. This is an agreement on end-user rights and not an agreement concerning sale.

  • Page 7: Nokia Mediamaster Software, End-user License

    Nokia Mediamaster software end-user license rights automatically and immediately terminate cluding governmental research institutions, govern- without notice from Nokia if You fail to comply with mental corporations, or their separate business any provision of this Agreement. In such an event,...

  • Page 8: General Information About The Mediamaster 310 S

    Discover digital television with interactive services The Nokia Mediamaster 310 S digital satellite TV receiver comes with full MHP (Multimedai Home Platform) standard support. MHP gives you access to a variety of useful interactive services.

  • Page 9: Remote Control

    Remote control This section describes how to operate the Mediamaster using the buttons on the remote control. Some of the functions can also be carried out using the buttons on the front panel. Press and hold for a few seconds to switch the Mediamaster in and out of standby mode.

  • Page 10: Front And Rear Panel

    Front and rear panel Front panel to change channels open the lid in order and to move in menus to insert the CA module and the smart card Slot Slot for a CA module for inserting of a with a smart card Conax smart card Button Indica-...

  • Page 11: About The Smart Card And Ca Module, General, The Right-hand Card Slot

    Service Provider. Note: CA modules and smart cards are only distributed by serv- ice providers and special distributors, not by Nokia. After inserting a card, leave it in the slot permanently. Do not re- move it again, unless you will be asked to do so. This is impor-...

  • Page 12: Installation Of The Mediamaster, Preparing The Remote Control, Connecting The Mediamaster To The Dish

    Installation of the Mediamaster The box for your Mediamaster should contain the following items: Remote control • the Mediamaster • remote control with 2 AAA batteries • SCART cable (fully connected 1.0 metre) • mains cable • phone cable with connectors •...

  • Page 13: General, Connecting To The Tv, Connecting A Tv And Vcr

    • Connect the TV aerial to the RF input socket on the analogue receiver. In order to switch the signal from the dish between the ana- logue and digital receivers, you need a Nokia smart switch (at Analogue A B in the diagram) or a Universal Twin LNB. >>>>>>>>>>...

  • Page 14: Connecting A Hifi System, Connecting To The Built In Phone Modem

    Installation of the Mediamaster Nokia smart switch • Connect a coaxial cable between output A on the smart switch (accessory) to the LNB socket on the analogue receiver. • Connect a coaxial cable between output B on the smart switch to the ANTENNA socket on the Mediamaster.

  • Page 15: First Time Installation, General Information, Regional Settings

    First time installation General information Once you have correctly connected the Mediamaster, you also have to perform a “First time installation”. During this procedure, helpful information is displayed at the bottom of the menus. Please note! The ok button on the remote control always confirms a selec- tion within these menus, and pressing it will take you to the next step in the installation process.

  • Page 16: Antenna Type Selection

    First time installation Antenna type selection One LNB • Select the first line One LNB when you have one antenna with an LNB directed towards one satellite. ☛ • press ok to continue. LNB type Select the correct LNB type for your configuration. Universal and some LNBs with fixed frequencies can be selected using the buttons.

  • Page 17: Diseqc 2 Input Switch

    First time installation DiSEqC 2 Input Switch Select this alternative if your antenna system has two (2) LNB:s and a 2-way DiSEqC switch. In this case you must first connect the LNBs to an external ☛ switch since there is only one antenna input on the Mediamaster. Once installed the switch automatically selects the correct LNB for the selected channel.

  • Page 18: Diseqc 4 Input Switch, Mini Diseqc Switch

    First time installation Predefined channel Select one of the predefined channels and adjust the antenna until you have a TV picture from the predefined channel visible ☛ in the background. Perform the same procedure for the second DiSEqC port. ☛ But this time select Switch port 2 and Astra as the satellite.

  • Page 19: Motor Antenna Configuration

    • From the Antenna Type Selection menu select option Mo- tor Antenna and press ok. ☛ Type of motor • Select SatScan when you have a Nokia SatScan motor. • Select DiSEqC when the motor that you have is controlled by DiSEqC commands. LNB type Select the correct LNB type for your configuration.

  • Page 20: Channel Search

    First time installation Channel search The Channel search procedure can be performed in different ways. ☛ Automatic search • Press ok to start searching for channels. Manual search The information you need to enter in this menu is available in magazines covering satellite TV reception or on the Internet.

  • Page 21: Channel Search In Progress, Finish The First Time Installation

    First time installation Channel search in progress This menu will be shown as long as the Mediamaster is search- ing for TV and radio channels. All channels found will be listed on the screen. Please note that the search procedure may take a few minutes. You can cancel the search at any time by pressing ok.

  • Page 22: Viewing Mode, General Information, Programme Information

    Viewing mode General information The following describes the basic functions of your Mediamaster while watching satellite TV or listening to satellite radio. Some of the functions described here are dependent on the Service Provider and can only be used if they are included in the transmitted programme information.

  • Page 23: The Options Menu, Extended Programme Information

    Viewing mode Extended programme information The Mediamaster can display information about programmes cur- rently being broadcast as well as those that will be broadcast next. This procedure is the same for both TV and radio mode. By pressing info while watching TV you will get the Programme information banner.

  • Page 24: Guide, Teletext, Tv Release (0)

    Viewing mode Guide Electronic Programme Guide, EPG By pressing the guide button you get access to the Mediamaster TV guide (or Radio guide when you are listening to radio channels) which will give you different programme information. Different alternatives of EPGs may also be provided depending on Service Provider.

  • Page 25: Navi Bars, General Information, The Settings Folder

    Navi Bars General information Bookmark Bookmark In order to select TV/Radio channels and to change system set- name tings you will use the Navi Bars. See figure to the right. • Press navi to open the Navi Bars. The horizontal row contains folders, e.g. All TV, Settings, Games and other.

  • Page 26: System Info

    Navi Bars User Banner Time-out When you switch channels, an information banner will be shown for a while. You can select for how many seconds the banner will be shown before it disappears. Volume bar Select whether you want the volume bar to appear on the screen or not when you change the volume.

  • Page 27: Edit Channels

    Navi Bars Edit channels The TV and Radio folders may contain many channels. Using the Edit Channels, you can create and edit favourite channel lists. The lists you create will appear as new folders in the Navi Bars. You can add, delete, rename, and arrange the order of the channels in your favourite lists.

  • Page 28

    Navi Bars Lock channels To open this menu, you will be asked to enter your access code. The access code is set to 1234 at the factory. You can lock (and later unlock) channels on any of the lists in order to prevent, for example, your children from watching.

  • Page 29

    Navi Bars The available characters are listed below. m n o ö 6 O Ö @ 1 . , ! ? p q r s 7 P Q R S a b c 2 å ä Å Ä t u v 8 T U V d e f 3 E w x y z 9 W X Y Z g h i 4 G H I...

  • Page 30: Timer

    Navi Bars Timer General You can program the Mediamaster to start and stop at predefined times. The timer function is very useful when you want to record a pro- gramme and you are unable to start/stop the recording event yourself, or when you just want to be reminded of the start of a programme you do not want to miss.

  • Page 31: Antenna

    Navi Bars Antenna To open this menu you will be asked to enter your access code. From the factory the access code is set to 1234. The lines Change antenna type and Modify antenna settings ☛ ☛ will get you to the same settings as explained in the pages 16-18. Edit Satellites Use this alternative if you are going to watch channels from a not pre-programmed satellite.

  • Page 32: Channel, Tv Settings

    Navi Bars Channel The procedure is the same as performed during the First Time In- stallation. Please refer to page 20-21. Looking for new channels TV and radio channels are continously added, moved or deleted on the different satellites. Make a new channel search now and then to keep your lists up-to-date.

  • Page 33: Access

    Navi Bars Picture format If you have a TV set with the 4:3 picture format and the transmis- sion is in 16:9, you can select “Fullscreen” or “Letterbox”. Fullscreen will fill up the screen but cut off some information on the left and right sides.

  • Page 34: Sw Update, Reinstall

    To see if there is any new software available for downloading, please visit www.nokia.com > Home Products > Support on the Internet If a new version is available and you continue with the update, all your previous settings, access code and favourite channels etc.

  • Page 35: Modem Setting

    Navi Bars Modem Setting To open this menu you will be asked to enter your access code. From the factory the access code is set to 1234. The Mediamaster is equipped with a built in telephone modem. Via the modem so called “interactive services”, such as e.g. or- dering movies, can be performed.

  • Page 36: Common Interface

    Navi Bars CA menu A CA menu will appear as a new bookmark in the settings folder when you have a smart card from Conax inserted in the right-hand card slot. Common Interface When you use a CA module and a smart card in the left-hand slot you may get a new bookmark in the Navi Bars.

  • Page 37: Language Settings, The "games" Folder

    Navi Bars Language settings Country Select the country where the box is located. This will also affect the time and the modem settings. Menu language Here you may select in which language the menus will be shown. Main subtitle language Select the preferred language for subtitling.

  • Page 38: Glossary Of Terms

    Glossary of terms AC-3 Network Multichannel digital audio encoding system. A number of digital channels transmitted from one source. Grouped under separate headings in the channel Access control list. A feature that allows parents to ”lock” programmes that they consider unsuitable for children. A ”locked” chan- nel or programme can only be ”unlocked”...

  • Page 39: Troubleshooting

    Troubleshooting Problem Possible causes What to do The LED on the front panel does Mains cable is not connected. Check that the mains cable is plugged not light up/is not lit. into the power socket. The left LED is shining red The Mediamaster is in standby Press the standby button to bring the mode.

  • Page 40: Technical Specifications

    Technical specifications Transmission standards DVB, MPEG 2 Front panel 2 LEDs, Buttons: (standby, progr. number up LNB / Tuner input and down) Connector 1x F-type (LNB) Conditional Access system RF input frequency 950-2150 MHz Embedded Conax. One PCMCIA Interface for a DVB Modulation QPSK Common Interface CA-module.

  • Page 41

    Nokia is a registered trademark of Nokia Corporation www.nokia.com 667790210.00...
