VIPER / VIPER-Lite AEL Embedded Linux Dev. Kit Quickstart
Ethernet data
cable
For all connections, the red wire on the cable is pin 1. Pin 1 on each connector is
marked on the board.
2
The VIPER I/O board can be attached above the main VIPER / VIPER-Lite board
once all connections to the main board are complete.
Audio input/output
AC power supply
Reset switch
© 2007 Eurotech Ltd
Issue C
COM1 (with null modem adapter attached)
Unpacking and connecting up
Ethernet LED
cable
Ethernet
breakout
VIPER
FPIF-CRT
11
