NetPing IO v2 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

[ENG] NetPing IO v2, User guide


Advertisement

Table of Contents
loading

Related Manuals for NetPing IO v2

Summary of Contents for NetPing IO v2

  • Page 1   [ENG] NetPing IO v2, User guide  ...

  • Page 2: Table Of Contents

    [ENG] NetPing IO v2, User guide - Содержание   [ENG] [IOv2] Introduction ................... 4 [ENG] [IOv2] Liability and Copyright ................5 [ENG] [IOv2] Connectors and Indicators ..............6 [ENG] [IOv2] Installation and Connection..............9 [ENG] [IOv2] Operating and Storage Conditions ............. 12 [ENG] [IOv2] Using IO Lines to Control External Devices (in an «output»...
  • Page 3 [ENG] NetPing IO v2, User guide -                              – ...

  • Page 4: [Eng] [Iov2] Introduction

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Introduction [ENG] [IOv2] Introduction This user guide will help to learn the operating peculiarities of the NetPing IO v2 device, get an idea about its features and technical specifications, and prepare a device for the operation.

  • Page 5: [Eng] [Iov2] Liability And Copyright

    User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying, replication and translation of this user guide to other languages are not allowed without a prior written permission are not allowed without a of a rightholder.

  • Page 6: [Eng] [Iov2] Connectors And Indicators

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Connectors and Indicators [ENG] [IOv2] Connectors and Indicators A front panel of a NetPing IO v2 device is represented on the picture below: On a front panel of a device, there are 2 Ethernet 10/100-BASE-TX sockets. A device can be connected to the Ethernet network using any of these connectors.
  • Page 7 LED blinks once for each received package. Back panel of a NetPing IO v2 device is shown on the picture below: 1 – +U (power), 2 - +U (power), 3 – GND (ground), 4 – IO 1 (input/output1), 5 – IO 2 (input/output2), 6 – IO 3 (input/ output3), 7 – IO 4 (input/output4), 8 – +3V3, 9 –...
  • Page 8 [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Connectors and Indicators +U – power voltage of a device +12V.  The second contact +U is used to power connected sensors. IO1 ... IO4 – are input/output lines for connecting external sensors and executive mechanisms. Each line may be configured individually as an input or an output.

  • Page 9: [Eng] [Iov2] Installation And Connection

    Insert wires in necessary connectors and tie them up with a screw; Plug a standard power supply unit of a device to power connectors, by using an adapter for NetPing IO v2. Plug a red wire of an adapter into an output 1, and a black wire into an output 3; ...
  • Page 10 [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Installation and Connection Insert a power supply unit to an electric outlet. A power indicator will light up; Insert an Ethernet cable into any Ethernet port of a device, plug it to a switch or directly to a network card of a computer;...
  • Page 11 [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Installation and Connection To perform an initial configuration of parameters of a device using a web interface, make sure that a device responds to a command ping its IP address; To configure a device, go to a web interface of a device via the address http://192.168.0.100 using a browser (it is desirable to use a browser Google Chrome of the latest version).

  • Page 12: [Eng] [Iov2] Operating And Storage Conditions

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Operating and Storage Conditions [ENG] [IOv2] Operating and Storage Conditions A device is designed for continuous round the clock operation indoors. In operating conditions of use, a device is resistant to an environment with temperature in a range of 0°С - +40°С (32 – 104 degrees Fahrenheit) and relative humidity in a range of 5% - 95 % at 25°С...

  • Page 13: [Eng] [Iov2] Using Io Lines To Control External Devices (In An "Output" Mode)

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Using IO Lines to Control External Devices (in an «output» mode) [ENG] [IOv2] Using IO Lines to Control External Devices (in an «output» mode) Input-Output (IO) lines of a device can be used for an input work as well as in an output mode for managing external devices.

  • Page 14: Equivalent Сircuit

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Using IO Lines to Control External Devices (in an «output» mode) Equivalent Сircuit [ENG] [IOv2] Using IO Lines to Control External Devices (in an «output» mode)                              – ...

  • Page 15: [Eng] [Iov2] Plugging Sensors

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Plugging Sensors [ENG] [IOv2] Plugging Sensors It is prohibited to plug sensors and external modules into NetPing devices when a power supply is on! Plugging a Door Sensor A sensor is a «reed contact», therefore the order of connecting wires does not matter.

  • Page 16: Plugging A Glass Breaking Sensor

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Plugging Sensors independently with the help of any wire with a minimum cross section of 0,4 mm . Maximum allowable length of a flat cable is 100 m. Plugging a Glass Breaking Sensor Surface security sound detector «Glass-3» is designed to detect breaking glass sheets.

  • Page 17: Connecting Leakage Sensor H2O

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Plugging Sensors independently with the help of any wire with a minimum cross section of 0,4 mm . Maximum allowable length of a flat cable is 100 m. Connecting Leakage Sensor H2O To plug a sensor, there is a need to connect:...

  • Page 18: Plugging 220V Occurrence Sensor

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Plugging Sensors Plugging 220V Occurrence Sensor A sensor is a «dry contact», therefore an order of connecting wires does not matter. Contact Name One of IO Lines – 1 - 4 A sensor will be displayed in a device interface as a status of an IO line to which it is connected.
  • Page 19 [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Plugging Sensors Colored Loop NetPing IO v2 Terminal +U (+12V) Important! Corresponding IO line must be set to an “input” mode in settings of a device. A sensor is packaged with an inseparable cable, with connectors on the ends. A cable length can be increased with the help of flat cable extenders of...

  • Page 20: [Eng] [Iov2] Resetting Parameters To Default Values

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Resetting Parameters to Default Values [ENG] [IOv2] Resetting Parameters to Default Values To reset parameters to default values, perform the next actions: • Power off a device; • Install a jumper; •...

  • Page 21: [Eng] [Iov2] Warranty

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Warranty [ENG] [IOv2] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used.

  • Page 22: [Eng] [Iov2] Additional Documents And Links

    [ENG] NetPing IO v2, User guide -[ENG] [IOv2] Additional Documents and Links [ENG] [IOv2] Additional Documents and Links A device webpage on a manufacturer's website is located at http://www.netpingdevice.com/products/netping-io- Manufacturer's website: http://www.netpingdevice.com Technical support contacts: http://www.netpingdevice.com/support Phone: +886-2-23121582 E-mail: support@netpingdevice.com [ENG] [IOv2] Additional Documents and Links...
