Mounting Height, Clearance, & Ducting
D
n .
m i
E
n .
m i
F
x .
m a
A : Minimum Ducted Hood Height
B : Minimum Recirculating Hood Height
C : Maximum Hood Height
D : Minimum Ducted Ceiling Height
E : Minimum Recirculating Ceiling Height
F : Maximum Ceiling Height
Standard Duct Cover
ZAZ ZLC
A 31- " 29"
1/2
B 36" 32- "
1/2
C 50" 46- "
1/2
D 89" (7' 5")
91- " (7' 7- ")
1/2 1/2
E 96" (8' 0")
92- " (7' 8- ")
1/2 1/2
120" (10')
F
116- " (9' 8- ")
1/2 1/2
Extension Duct Cover
ZAZ ZLC
A 47" 47"
51"
B 51"
C 80"
80"
D 107" (8' 11") 107" (8' 11")
E 111" (9' 3") 111" (9' 3")
F 150" (12' 6") 150" (12' 6")
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
A
n .
m i
B
n .
m i
C
x .
m a
i n .
.
" m
a x
2 4
" m
3 4
"
3 6
ZRM ZRE
28" 28- "
1/2
31" 28- "
1/2
39" 39"
88" (7' 4")
88- " (7' 4- ")
1/2 1/2
91" (7' 7")
88- " (7' 4- ")
1/2 1/2
109" (9' 1") 109" (9' 1")
ZRM ZRE
50- " 48- "
1/2 1/2
50- " 48- "
1/2 1/2
80" 78"
110- " (9' 2- ") 108- " (9' ")
1/2 1/2 1/2 1/2
110- " (9' 2- ") 109- " (9' ")
1/2 1/2 1/2 1/2
150" (12' 6") 148" (12' 4")
Installation Instructions
A minimum of 6" round duct must be used to maintain
maximum air flow efficiency.
Always use rigid type metal ducts only. Flexible ducts could
restrict air flow by up to 50%.
Also use calculation (on page 8) to compute total available
duct run when using elbows, transitions and caps.
ALWAYS, when possible, reduce the number or transitions
and turns. If long duct run is required, increase duct size.
If turns or transitions are required; install as far away from
hood duct output and as far apart, between the two as
possible.
Minimum mount height between range top to hood bottom
should be no less than 24". Maximum mount height should
be no higher than 34".
It is important to install the hood at the proper mounting
height. Hoods mounted too low could result in heat
damage and fire hazard; while hoods mounted too high
will be hard to reach and will lose its performance and
efficiency.
If available, also refer range manufacturer's height
clearance requirements and recommended hood mounting
height above range.
For shipment and installation damages:
►
Please fully inspect unit for damage before installation.
►
If the unit is damaged in shipment, return the unit to the
store in which it was bought for repair or replacement.
►
If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
►
If the unit is damaged by the installer (if other than
the customer), repair of replacement must be made by
arrangement between customer and installer.
