Ductless Recirculation

Ductless recirculation is intended for applications where an exhaust duct work is not possible to be
installed. When converted, the hood functions as a recirculating hood rather than an exhaust hood.
Fumes and exhaust from cooking are drawn and filtered by a set of optional charcoal filters. The air is
then purified and re-circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new
duct work, if possible. The hood is most effective and efficient as an exhaust hood. Only when the
exhaust option is not possible should you recourse to converting the hood into a recirculating hood.
When converted to be a recirculating hood, a set of charcoal filters are required on top of its standard
Metal Filter set. Order according to its part number below. The standard mesh filters are intended to
capture residue from cooking, and the optional charcoal filters help to purify fumes exhausted from
cooking for recirculation.
Recirculating Kit Installation (required if no ducting is used)
For detailed installation instructions, please refer to the manual included with the recirculating kit.
The kit includes the charcoal filters, filter attachment clip, and air diverter plate.
Recirculating Kit
Hood Model
ZAZ
ZLC
ZRM-E36DS
ZRM-E42DS
ZRE
1. Purchase recirculating kit per the part number above. Secure air diverter plate to top support
frame. Open sides of air diverter plate should face left and right to direct air through the louver
holes located on the top duct cover. Run 6" ducting from top of hood and secure to air diverter
plate.
2. Remove mesh filters from hood. Install charcoal filters as referenced with the manual included with
recirculation kit. Reinstall mesh filters.
3. Turn on charcoal filter replace indicator on control panel. The microprocessor in the controls will
indicate the need to change the charcoal filter after 120 hours of continuous use.
DO NOT WASH CHARCOAL FILTERS. Charcoal filters may need to be changed more often depending
on cooking habits.
Anzio Island, Luce Island, Roma Island, Ravenna Island Use, Care, and Installation Guide
Quantity to
Part Number
ZRC-02AZ
ZRC-00LC
ZRC-02RM
ZRC-01RM
ZRC-00RE
Installation Instructions
Charcoal Filter
Replacement Part
Order
2
1
2 Z0F-C002
3 Z0F-C002
2 Z0F-C002
Number
Z0F-C091
Z0F-C092
Quantity to
Order
2
1
2
3
2
