Scarborough Four Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
C
dowel
long
bolt
x14
x40
screw x6
H
I
J
slide
slide
bracket
x4
rail x4
rail x4
Q
O
P
allen
leg bracket
bolt
key x1
x4
x4
WARNING:
Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
D
E
locking
screw
x52
nut x40
K
L
cover
plug
x4
x4
R
S
screw
small bolt
x8
x16
Hardware Supplied
Phillips & Flathead screwdrivers
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
F
G
slide
slide
rail x4
rail x4
M
N
screw
screw
x20
x8
T
U
felt pad
wedge
x8
x4
V
W
X
safety
screw
wall
x1
strap x1
anchor
x1
Wall Strap
Y
Z
wall
washer
x2
screw
x1
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mocka Scarborough Four Drawer
Summary of Contents for Mocka Scarborough Four Drawer
- Page 1 Phillips & Flathead screwdrivers For quicker assembly, we recommend the use of a power drill on a low-speed setting. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 2 Attach 4x slide rails (F) to panel [3] as shown with 12x screws (E). Insert 4x bolts (C) into panel [1] and tighten with a screwdriver. Tighten with a screwdriver. Insert 8x bolts (C) into panel [3] and tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 3 Tighten with a screwdriver. Insert 8x bolts (C) into panel [4] and Tighten with a screwdriver. Place 4x covers (K) over the brackets tighten with a screwdriver. (J) as shown. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 4 Attach panels [5], [6] and [7] to panel [3] with 3x dowels (A) and Slide panel [8] down along the grooves between panels [3] secure with 8x locking nuts (D). Tighten with a screwdriver. and [4]. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 5 Attach panel [4] to panels [5], [6] and [7] with 3x dowels (A) and Slide panel [8] down along the grooves between panels [3] secure with 8x locking nuts (D). Tighten with a screwdriver. and [4]. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 6 Slide panel [8] down along the grooves between panels [3] secure with 4x locking nuts (D). Tighten with a screwdriver. and [4]. Attach panel [1] to panel [5] secure with 2x long screws (B). Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 7 [9] to panel [2] using 4x small bolts (S) as shown. Tighten with the Allen key (O). Attach 4x felt pads (T) to the ends of the legs. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 8 Insert 5x bolts (C) into panel [10]. Attach 1x plug (L) to panel [10] Attach panels [11], [12], [13] and [15] as shown using 5x screws (M). and secure with 1x screw (E).Tighten with a screwdriver. Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 9 Slide panels [14] down along the grooves between panels [11] Attach panel [10] to panels [11], [12] and [13] using 5x locking nuts (D). and [12]. Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 10 Insert the drawers into the unit as shown. If the door is not catching or as shown. Secure with 4x screws (E) and tighten with a screwdriver. sitting flush, twist the end of the cover (K) until it catches on the plug (L). mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 11 [1] using 1x washer (Z) and 1x screw (W). Tighten with a Fasten to the wall using 1x washers (Z), 1x wall anchor (X) and screwdriver. 1x screws (Y). Ensure unit is balanced and steady before use. You’re done, enjoy! mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
