Scout Desk
Assem b ly I nst ruct io ns
Th an k y o u f o r y o u r p u rch ase.
Pl ease f o l l o w t h e i n st r u ct i o n s b el o w f o r c o r rect a ssem b l y.
A
B
b o l t
50m m s crew
x16
x2
E
F
F2
F1
15m m s crew
sl i d e r ai l
x3
x4
I
J
d o w el
screw
x16
x5
M
N
25 mm screw
wall anchor
x2
x2
H ard w are Su p p l i ed
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C
D
40m m s crew
30m m s crew
x4
x16
G
H
12m m s crew
50m m s crew
x16
x16
K
L
f o o t s t o p
safety strap
x2
x2
WARNING:
Any furniture that is not anchored to a wall has the potential to
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with
all furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please
note that different wall materials may require different fixing devices from
those supplied.
Phillips & Flathead screwdrivers required.
Fo r q uicker a ssem b ly, w e r eco m m end t he
use o f a p o w er d rill o n a l o w - sp eed set t ing .
1
