Rear View

The illustration below shows the features included on the rear of the chassis. The power
supply module displays status lights.
Antenna Cut-out
Power Input
Feature Description
Power Input Use this port for the 60W DC power input.
Antenna Cut-outs Two cut-outs for mounting antennas.
LAN Ports Four 1GbE network ports.
HDMI One HDMI port.
SIM Slots Three SIM slots.
USB Two USB 3.0 ports.
Kensington® Lock One slot for Kensington security cable/lock.
LAN Ports
HDMI Port
Figure 1-3. System Rear View
System Features: Rear
11
Chapter 1: Introduction
USB 3.0 Ports
SIM Slots
Antenna Cut-out
Kensington Lock
