PRODUCT NAME: Hazel Dining Chair
ITEM NUMBER: UD217
ASSEMBLED DIMENSIONS : 32"H x 24.5"W x 22"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 8-6-2020
Uncrating and Assembly Instructions
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA
Page 1 of 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ballard Designs Hazel UD217
Summary of Contents for Ballard Designs Hazel UD217
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Hazel Dining Chair ITEM NUMBER: UD217 ASSEMBLED DIMENSIONS : 32”H x 24.5”W x 22”D Uncrating and Assembly Instructions PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE. UPDATED: 8-6-2020 Page 1 of 3...
- Page 2 REQUIRED TOOLS: Ltr. Qty. Hardware Included Allen Wrench (included) Allen Wrench -Two person assembly suggested. STEP 1: Stand Chair upright as illustrated below and remove all four Bolts from Top using Allen Wrench. Carefully remove Top and set aside. STEP 2: Set Chair onto its side as illustrated below, remove all four Bolts from bottom corners then set Support posts aside.
- Page 3 STEP 3: With Chair still on its side, use fingers to carefully remove all four Levelers from bottom of Chair legs. Remove shipping panel and set aside. Replace Levelers onto each leg. LEVELERS Remove and Replace After installation, Chair level may be adjusted by turning Levelers clockwise/counterclockwise. Customer Service: 800-367-2810 Online: www.ballarddesigns.com Page 3 of 3...
