Technical Specifications

This chapter provides important technical specifications related to the device.
5.1

Power Supply Specifications

Note
When determining cable lengths, make sure the nominal input voltage for the power
supply is provided at the power source.
HI (125/250 VDC)
HI (110/230 VAC)
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than
fiber optic ports.
d
This is the same power supply for both AC and DC.
5.2

Failsafe Relay Specifications

5.3

Copper Ethernet Port Specifications

The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM RS8000A.
Speed
Connector
Duplex
RUGGEDCOM RS8000A
Installation Manual, 12/2021, C79000-G8976-1021-06
Power
Supply Type
Minimum
12-24 VDC 10 VDC
24 VDC 18 VDC
48 VDC 36 VDC
d
88 VDC
d
85 VAC
Voltage
30 VAC
30 VDC
80 VDC
a
10/100Base-TX
RJ45
a
FDX/HDX
Input Range
Maximum
36 VDC
36 VDC
59 VDC
300 VDC
265 VAC
Internal Fuse Maximum Power
ab
Rating Consumption
6.3 A(F)
5 A(F)
3.15 A(T) 15 W
3.15 A(T)
3.15 A(T)
Current
0.3 A
1 A
0.3 A
5
