Installing the Device
2.2.2 Mounting the Device to a Rack
Removing the Device
To remove the device from a DIN rail, do the following:
1.
2.
3.
2.2.2

Mounting the Device to a Rack

To secure the device to a standard 48 cm (19 in) rack, do the following:
1.
10
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
3
1
2
1
DIN Rail
1
DIN Rail Adapter
2
Figure 2.2 Removing the Device from a DIN Rail
Swing the bottom of the device away from the DIN rail.
Lift the device off the DIN rail.
Remove the four screws from the side of the device.
2
RUGGEDCOM RS8000A
Installation Manual, 12/2021, C79000-G8976-1021-06
