B&D Auto-Lock Kit Installation Instructions page 3

Auto-Lock Kit - Installation instructions
limited side room installation
preparation - brackets, mounting on door
a. Remove the lock
drive unit from the
lock mechanism by
depressing the two
tabs on the top and
bottom of the unit
and pulling apart.
StormShield and Tongue & Groove installation
preparation - mounting on door stile
1
8 9
3
a. Fit the mounting bracket
or to the lock
8 9
mechanism using
1
2 x countersunk head
screws M6 x 14 .
3
(door mount)
1
10
b. Close door and mark mounting position of
both striker and lock, by holding in place.
c. Open door and affix the striker bracket
the track with 3 x bolts
d. Close the door, align the lock mechanism
on the bottom panel door stile so that
1
the lock bolt engages fully into the striker
bracket and fix using 4 x flange head tek
6
screws .
10
12
b. Close the door to determine mounting
position between the reinforcing braces
on the bottom door panel and mark.
Mount the bracket and lock mechanism as
marked with the 4 flange head tek screws
20 x 25 CL4 , however do not fully tighten
10
as further final adjustment may be required.
c. With the door in the closed position align
the striker bracket with the lock
d. Drill 3 x ¼ holes as marked in the tracklock
and fix with 3 x bolts
11
12
6
to
6
and nuts .
11 12
(kits sold separately)
11
10
and nuts .
11 12
e. Fit the lock drive unit to the lock
mechanism.
f. Test the operation of the AutoLock by
pressing the lock/unlock button to
ensure the lock bolt fully engages the
striker without interference.
PROCEED TO CONNECTING BASE STATION
TO THE OPENER.
e. Test the operation of the AutoLock
by pressing the
button to ensure the lock bolt
fully engages the striker without
interference.
PROCEED TO CONNECTING
BASE STATION TO THE OPENER.
3
lock/unlock
