Computers Connection

LevelOne Palm-Sized KVM comes with complete cable
sets facilitating computer connection. One side of the
cable has an HDB-15 connector and the other side has
three connectors (one HDB-15 and two mini-DIN6s).
The PC 1 ~ PC 4 marks on the LevelOne Palm-Sized
KVM are for computer connection as shown in figure 3.
Figure 3: COMPUTER Connection
NOTE: If your computer uses an AT style keyboard, you
will need an "AT-to-PS/2 keyboard adapter" at the
computer keyboard port.
5

Initial Power-up

Make sure all computers and
Palm-Sized KVM are powered
installation. You may power up the computers after
installation,. The LevelOne Palm-Sized KVM can be
powered from the computers.
ensures the LevelOne Palm-Sized KVM receive
computer settings correctly when computer boots.
NOTE: You may hot plug any additional powered-down
computer to the LevelOne Palm-Sized KVM at any time
after the initial power up.
6
the LevelOne
down during
This procedure
