EXPERT GRILL XG17-096-034-17 Owner's Manual

Tabletop gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tabletop Gas Grill
Model No.
WARNING
FOR YOUR SAFETY:For Outdoor Use Only (outside any enclosure)
DANGER
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the appliance and immediately call your fire department.
Failure to follow these instructions could result in fire or explosion which could cause property
damage, personal injury or death.
DANGER
Never operate this appliance unattended.
Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily
injury or death, or in a fire or an explosion causing damage to property.
XG17-096-034-17
Page 1

Advertisement

Table of Contents
loading

Related Manuals for EXPERT GRILL XG17-096-034-17

Summary of Contents for EXPERT GRILL XG17-096-034-17

  • Page 1 Tabletop Gas Grill Model No. XG17-096-034-17 WARNING FOR YOUR SAFETY:For Outdoor Use Only (outside any enclosure) DANGER If you smell gas - 1. Shut off gas to appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your fire department.

  • Page 2: Important Safeguards

    Model No. XG17-096-034-17 FOR YOUR SAFETY 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment. 3. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.
  • Page 3 Model No. XG17-096-034-17 LP gas cylinder must be arranged for vapor withdrawal. Dented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to use. The LP gas cylinder should not be dropped or handled roughly.
  • Page 4 Model No. XG17-096-034-17 Inspect grill before each use. Do NOT alter grill in any manner. Any alteration will void your warranty. Do NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened. This grill should be thoroughly cleaned and inspected on a regular basis.
  • Page 5 Model No. XG17-096-034-17 Failure to open lid while igniting the grill’s burner(s), or not waiting five minutes to allow the gas to clear if the grill does not light, may result in an explosive flame-up. Never operate grill without its heat plates installed.
  • Page 6 Model No. XG17-096-034-17 Important Safeguards......Page 1 Preparation............6 Exploded View........... 7 Parts List............8 Hardware & Tools..........9 Assembly Instruction........10 Operating Instructions........15 Cleaning and Care........... 17 Limited Warranty..........19 Preparation DO NOT RETURN PRODUCT TO STORE. For assistance, please call toll free number 1-855-328-4769 or email customerservice@sanxinint.com .Please have your owner’s manual...
  • Page 7 Model No. XG17-096-034-17 Page 7...

  • Page 8: Parts List

    Model No. XG17-096-034-17 Parts List Part Part Image Image Description Description Side Handle Heat Plate Lid Handle Support Lid Hinge Fire Bowl Cooking Regulator/ Grate Control Knob Heat Plate Right Leg Burner Lock Bottom Bowl Left Leg Heat Shield Bowl Hinge...
  • Page 9 Model No. XG17-096-034-17 Hardware Part Part Image Image Description Description M6*12 M5*12 Screw Screw Washer Cotter Pin Spring Washer Hinge Pin (Small) M6 Wing M5 Wing Large M4 Wing Washer Spring M4*12 Washer Screw (Big) Tools Required for Assembly (Not Included)
  • Page 10 Model No. XG17-096-034-17 Step 1 Note:Please find hardware J/K/L attached on lid handle. Step 2 Page 10...
  • Page 11 Model No. XG17-096-034-17 Step 3 Step 4 Note:Please find hardware J/K/L attached on side handle. Page 11...
  • Page 12 Model No. XG17-096-034-17 Step 5 Step 6 Page 12...
  • Page 13 Model No. XG17-096-034-17 Step 7 Step 8 Page 13...
  • Page 14 Model No. XG17-096-034-17 Page 14...

  • Page 15: Disconnecting Lp Gas Tank

    Model No. XG17-096-034-17 Figure 1 This grill is designed to operate with a 1 lb. 7.75 in. or 10.6 in. high disposable / 16.4 oz. or 14.1 oz.propane gas tank (DOT 39 Cylinder) (Figure 1). DO NOT ATTEMPT TO REFILL ANY 1 lb. (16.4 oz. or 14.1 oz.) PROPANE GAS TANKS!

  • Page 16: First Use

    Model No. XG17-096-034-17 (Figure 2). Figure 5 3. Spoon the leak detection check solution on all “X” locations (Figure 5). a. If any bubbles appear, remove the LP gas tank and reconnect, making sure the connection is secure. b. If you continue to see bubbles after several attempts, remove the LP gas tank per “Disconnecting LP Gas Tank”...

  • Page 17: Turning Off

    Model No. XG17-096-034-17 Turning Off 1. Turn regulator/control knob to the “OFF” position (Figure 2). Note: A “poof” sound is normal as the last of the LP gas is burned. 2. Disconnect LP gas tank per “Disconnecting LP Gas Tank ” section.

  • Page 18: Before Each Use

    Model No. XG17-096-034-17 Notices Figure 8 Burner Flame Conditions 1. This grill should be thoroughly cleaned and inspected on a regular basis. Use this chart to see if your 2. Abrasive cleaners will damage this product. burners need to be cleaned.

  • Page 19: Before Storing

    Model No. XG17-096-034-17 13. Replace heat plate and cooking grid. 14. Connect LP gas tank per “Installing LP Gas Tank” section. 15. Perform leak test per “Checking for Leaks” section. Before Storing 1. Turn LP gas tank valve to “CLOSED.”...
  • Page 20 Model No. XG17-096-034-17 Bazhou Sanxin Steel Pipe Co.,Ltd Address:Xin’an Town, Bazhou City, Hebei Province, China Page 20...
