Technical Reference Manual
TLA 700 Series
TLA 7QS QuickStart Training Board
070-9716-00
There are no current European directives that
apply to this product. This product provides cable
and test lead connections to a test object of
electronic measuring and test equipment.
This document supports firmware version 1.00
and above.
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.

Advertisement

Table of Contents
loading

Related Manuals for Tektronix TLA 700 Series

Summary of Contents for Tektronix TLA 700 Series

  • Page 1 Technical Reference Manual TLA 700 Series TLA 7QS QuickStart Training Board 070-9716-00 There are no current European directives that apply to this product. This product provides cable and test lead connections to a test object of electronic measuring and test equipment.
  • Page 2 Commercial Computer Software – Restricted Rights clause at FAR 52.227-19, as applicable. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved.

  • Page 3: Table Of Contents

    ..........Contacting Tektronix .
  • Page 4 2–29 Tektronix Software Tools ........
  • Page 5 Table of Contents JTAG Port ........... 4–14 Power Input Connectors .
  • Page 6 Table of Contents Replaceable Mechanical Parts Parts Ordering Information ......... 8–1 Using the Replaceable Mechanical Parts List .
  • Page 7 Table of Contents List of Figures Figure 2–1: Programmable delayed read memory block diagram . . . 2–3 Figure 2–2: Null modem connections ......2–7 Figure 2–3: Remote menu .
  • Page 8 Table of Contents List of Tables Table 2–1: Microprocessor chip select lines ..... 2–1 Table 2–2: PORTA signals ........2–2 Table 2–3: RS-232 connector pinouts .

  • Page 9: General Safety Summary

    General Safety Summary Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid potential hazards, use this product only as specified. Only qualified personnel should perform service procedures. While using this product, you may need to access other parts of the system.
  • Page 10 General Safety Summary Symbols and Terms Terms in this Manual. These terms may appear in this manual: WARNING. Warning statements identify conditions or practices that could result in injury or loss of life. CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.

  • Page 11: Service Safety Summary

    Service Safety Summary Only qualified personnel should perform service procedures. Read this Service Safety Summary and the General Safety Summary before performing any service procedures. Do Not Service Alone. Do not perform internal service or adjustments of this product unless another person capable of rendering first aid and resuscitation is present.

  • Page 12: Preface

    Preface The TLA 7QS Technical Reference Manual is an optional accessory to the TLA 7QS package. It is intended to provide technical and service information for the TLA 7QS training board. How to Use This Document The manual is made up of the following sections: The Getting Started chapter provides a brief overview of the product.

  • Page 13: Related Documentation

    The TLA 700 Series Logic Analyzer User Manual provides basic user information for the TLA 700 Series Logic Analyzers. Use the online help in the TLA 700 Series logic analyzer to obtain operating information and for specific information on windows, menus, and fields within the application.

  • Page 14: Getting Started

    The embedded programs are designed to send digital and analog signals to the various connectors on the training board. These signals can be used to demonstrate the capabilities of the TLA 700 Series Logic Analyzers.

  • Page 15: Functional Check

    Getting Started Functional Check The basic operation of the TLA 7QS training board is verified by the power-up diagnostics. The power-up diagnostics run at power-on or when the RESET signal is asserted by pressing the RESET button. To perform a more detailed functional verification of the training board, refer to the Functional Verification Procedures beginning on page 5–1.

  • Page 16: Hardware Features

    Hardware Features This section describes the hardware features of the TLA 7QS training board. It provides information on using the hardware to demonstrate features of logic analyzers and oscilloscopes. Detailed information on individual circuits is provided in the Theory of Operation beginning on page 4–1. Circuit Board Modules The training board can be divided into the following circuit board modules: Microprocessor module...

  • Page 17: Table 2-2: Porta Signals

    Hardware Features Microprocessor Interrupts. Four external interrupts are used on the training board: IRQ3*, IRQ5*, IRQ6*, and IRQ7*. You can assert the signals through the push buttons on the training board or through the parallel control port. Microprocessor Parallel Input/Output Port. The microprocessor has a general purpose parallel input/output port (PORTA) that uses the upper eight address lines.
  • Page 18 Hardware Features Figure 2–1 shows a block diagram of the programmable delayed read memory. Read strobe delay shift register 0–125 ns 62 ns/Step Upper byte programmable memory delay Delayed read strobe Shift In Out gen logic register Prog. delay Clockout line Dlyclksel0 Data<8..15>...

  • Page 19: Signal Sources Module

    Hardware Features Signal Sources Module The signal sources module consists of the following groups of signals that can be used to demonstrate logic analyzer and oscilloscope features: Counter and pattern generator signals Setup & Hold and trigger signals Tapped delay line Burst signal Glitch signal Metastable data and clock signals...

  • Page 20: User Interface Module

    Hardware Features Step Signal. Use the step signal to demonstrate analog bandwidth and triggering of oscilloscopes and logic analyzers. Runt Pulse and Missing Pulse Signal. Use the runt pulse and missing pulse signal to demonstrate oscilloscope pulse triggering features. You can also use it to demonstrate logic analyzer 4 ns counter/timers and time-qualified triggers.

  • Page 21: Input And Output Connectors

    Hardware Features LED Indicators. Two 10-segment LED indicators display bit patterns for various software and hardware demonstrations. The first sixteen LED segments (labeled 0 through 15) represent data bits. Bits 16 and 17 represent the LAPort input and output enable status. Bit 18 indicates whether the external trigger input is enabled.

  • Page 22: Table 2-3: Rs-232 Connector Pinouts

    Hardware Features Standard null modem connection Minimum null modem connection required for the training board Figure 2–2: Null modem connections Table 2–3 shows the connector pinouts for the DB9 and DB25 serial port connectors. Table 2–3: RS-232 connector pinouts Signal Name DB9 pins DB25 pins...

  • Page 23: Software Features

    Software Features This section describes software operation, embedded programs, and diagnostics available with the TLA 7QS Training Board. When you first apply power to the the training board, or when you press the Reset button, the training board initializes the 68340 registers, runs the power-on diagnostics, and then starts the normal operation.

  • Page 24: Debug Mode

    Software Features NOTE. You may need to use a null modem to connect the training board to your PC. For information on using a null modem, refer to Serial Port Requirements on page 2–6. Additional menu choices are available that are not used in the stand-alone mode. These choices include downloading an S-record file to user flash memory and starting the SDS (Software Development Systems) target monitor program.

  • Page 25: Lites

    Software Features LITES The Lites program strobes the LED segments from right to left and then left to right. The program also writes the phrase “Making It Happen” to Serial Port B. STOP LITES The Stop Lites program lights specific LEDs in a predetermined sequence. The LEDs are lighted in a sequence to emulate two traffic lights (hence the name Stop Lites).

  • Page 26: Wait State

    Software Features WAIT STATE The Wait State program varies the M68340 wait states from zero to three on CS2 and CS3. After starting the program, push the F1 button to select the number of wait states. You can then use a logic analyzer to capture and analyze the impact of the wait states on system performance.

  • Page 27: Setup/Hold

    Software Features SETUP/HOLD The Setup/Hold program controls the Setup and Hold circuitry on the training board (J850). The program sends a four bit count pattern to DATA pins 0–3 (J850-1 though J850-4). The same pattern is sent to the QOUT pins 0–3 (J850-5 through J850-8).

  • Page 28: Trig Enable

    Software Features Push the F3 button to count down to select the port lines. Push the F4 button to accept the changes. The three LAPort lines are selected by binary values from the F2 or F3 buttons. The value written to the output is displayed on the LCD as a binary number. For example, to set the LAPort output line 1 high and others low, select the binary value 010.

  • Page 29: Lcd User Interface

    Software Features LCD User Interface The LCD Interface consists of the liquid crystal display and four buttons on the training board. The UP, DN, RUN, and STOP images on the LCD correspond to the buttons located directly below the display. UP and DN Buttons Pushing either button causes interrupts.

  • Page 30: Diagnostics

    Software Features The interface runs at a baud rate of 9600 with hardware flow control. You should use a terminal emulation program on a PC such as HyperTerminal. The ANSI escape codes provide cursor control. Press an arrow key on the terminal keyboard to move between highlight selections in the menu.

  • Page 31: Rom Test

    Software Features The second test requires connecting a terminal to Serial Port A (9-pin submini- ture D connector). The test pauses until you connect the cable and then push the Run button to continue. The test string, “Testing serial port A,” is transmitted through the port.

  • Page 32: Memory Maps

    Memory Maps This section provides information on the memory maps for the TLA 7QS Training board. The first part of this section provides information on the memory mapped input and output. The rest of this section lists the actual memory maps. Memory Mapped Input and Output The training board has 2 Mbytes of memory mapped input and output.

  • Page 33: Input Control Bits Register

    Memory Maps Bit 17 represents the LAPort output enable status. The output circuit uses a transparent latch. When the LED is on (low signal), the output is enabled and signal changes on the training board are sent to the output port. When the LED is off, the output data is latched to last transmitted value (unknown at power-on).

  • Page 34: Output Control Bits Register

    Memory Maps Output Control Bits The output control bits register is a 16-bit input register used to assert signals. Register Table 2–6 lists the output control bits and the associated signals. See Figure 2–7 on 2–26 page for memory mapping information. Table 2–6: Output control bits Signal name Function...

  • Page 35: Low Counter Pattern Generator Data

    Memory Maps Low Counter Pattern The low counter pattern generator data register is a 16-bit write-only register that Generator Data stores a data value in the low counter pattern generator. High Counter Pattern The high counter pattern generator data register is a 16-bit write-only register Generator Data that stores a data value in the high counter pattern generator.
  • Page 36 Memory Maps 00 0000 2 MB User/System SRAM Space $20 0000 2 MB User EEPROM/Flash Space $40 0000 2 MB On Board Memory Space Input/Output 16 MB Address Space Space 24 Address Lines (A0—A23) $60 0000 2 MB System EEPROM/Flash Space $80 0000 8 MB...
  • Page 37 Memory Maps $00 0000 128 K X 16 K 256K SRAM $04 0000 $00 0000 Exception 128 K X 16 K 256K Vectors SRAM $00 03FF Monitor $08 0000 Supervisor Space $00 3FFF Supervisor 512K Unused Stack Pointer Space $00 7FFF User $10 0000 Stack Pointer...
  • Page 38 Memory Maps $20 0000 256K X 16 512K EEPROM/Flash $28 0000 512K Unused $30 0000 512K Unused $38 0000 512K Unused $3F FFFF Figure 2–6: User EEPROM and Flash 2–25 TLA QuickStart Technical Reference Manual...
  • Page 39 Memory Maps $40 0000 LCD Display 256K Output Read/Write $44 0000 LED Display 256K Output Write Only $48 0000 Input Control Bits 256K Read Only $4C 0000 Output Control Bits 256K Write Only $50 0000 Programmable 256K Delay Line Write Only $54 0000 Delay Line Memory 256K...
  • Page 40 Memory Maps $60 0000 256K X 16 512K EEPROM/Flash $68 0000 512K Unused $70 0000 512K Unused $78 0000 512K Unused $7F FFFF Figure 2–8: System EEPROM and Flash 2–27 TLA QuickStart Technical Reference Manual...

  • Page 41: Creating Programs For The Training Board

    To create programs for the training board you will need the SDS CrossCode C 68K software package from Software Development Systems (the C++ option is not required) and some software tools from Tektronix. You will use these packages to write the code and to download the programs to the training board.

  • Page 42: Writing The Program

    Creating Programs for the Training Board Writing the Program The following procedures provide information on writing the program code for the training board. You may want to refer to Appendix A: Source Code for a sample program. The procedures consist of the following steps: Create the menu entry Include the user header file Create a dummy function...

  • Page 43: Write The Code

    Creating Programs for the Training Board Write the Code Write your code using normal C or assembly language. You can use any of the functions for the training board, or create your own functions. Refer to Appen- dix A: Source Code for a sample program. You may also want to refer to the code supplied on the floppy disk accompanying this manual.

  • Page 44: Writing An Image To The Flash Memory

    Creating Programs for the Training Board Writing an Image to the Flash Memory Prepare to download the code into flash memory on the training board using a downloader utility. The downloader utility will extract code bytes and convert them into a Motorola S-record file. Make sure that you use the proper flags to avoid ending up with an extremely large file.

  • Page 45: Specifications

    Specifications This chapter contains the specifications for the TLA 7QS Training Board. Within each section, the specifications are arranged in functional groups such as: Microprocessor System Characteristics, Signal Source Characteristics, Hardware Characteristics, Power distribution, Mechanical Characteristics, and Environmental Characteristics. All specifications are warranted unless they are designated typical. Typical characteristics describe typical or average performance and provide useful reference information.
  • Page 46 Specifications Table 3–1: Microprocessor signal characteristics (Cont.) Characteristic Description System reset signal The reset signal is integrated into the M68340 microprocessor and connected to the external button to reset the system. External interrupt requests IRQ3, IRQ4, IRQ6, IRQ7 Memory-mapped functions Chip select decoder One of eight chip select decoders to select memory-mapped functions Input control bits register...

  • Page 47: Table 3-2: Signal Source Characteristics

    Specifications Table 3–2: Signal source characteristics Characteristic Description Counter/Pattern generator signals Number of counter bits One 32-bit counter or two 16-bit counters Counter clock frequency (typical) 50 MHz Number of pattern generator bits Pattern generator toggle bits Eight four-bit patterns Pattern generator toggle frequency 50 MHz, 10 MHz, 1.25 MHz, and programmable (typical)

  • Page 48: Table 3-3: Hardware Characteristics

    Specifications Table 3–2: Signal source characteristics (Cont.) Characteristic Description Runt pulse frequency (typical) 1.6 Hz to 2.5 Hz Missing pulse frequency (typical) 1.6 Hz to 2.5 Hz Staircase signals source Step intervals (typical) 0.5 ms per step Staircase interval (typical) 8.0 ms per staircase Amplitude (typical) 900 mV...

  • Page 49: Table 3-4: Power Distribution Characteristics

    Specifications Table 3–3: Hardware characteristics (Cont.) Characteristic Description LAPort input enable LED One LED connected to the LAPort input control bit. The LED is on when the LAPort input is enabled. Memory mapped LEDs 16 memory mapped LEDs Liquid crystal display Two line by 16 character LCD memory mapped display External interrupt request switches Four interrupt request signal switches for microprocessor signals IRQ3, IRQ4, IRQ6,...

  • Page 50: Table 3-5: Mechanical Characteristics

    Specifications Table 3–5: Mechanical characteristics Characteristic Description Construction material Circuit board Glass laminate Physical Dimensions Height 1.0 in (2.54 cm) Length 8.1 in (20.57 cm) Width 5.3 in (13.46 cm) Package Dimensions Height 3 in (7.62 cm) Length 12.9 in (32.77 cm) Width 11.4 in (28.96 cm) Shipping weight...

  • Page 51: Theory Of Operation

    Theory of Operation This chapter provides the theory of operation of the TLA 7QS training board. It provides information on the built-in circuit modules and on the connectors on the training board. Circuit Board Modules The following circuit board modules are discussed in this section: Microprocessor module Signal Sources module User interface module...

  • Page 52: Signal Sources Module

    127 ns. The time adjustment is fine enough so that it can be calibrated to be just on the threshold of creating a read error. You can use the high resolution (MagniVu) mode of the TLA 700 Series Logic Analyzers to demonstrate and measure small changes in delay adjustments.
  • Page 53 Theory of Operation Table 4–1: Output control bits (Cont.) Signal name Function EXTCLKEN External counter clock enable CNTR16BIT* 16-bit or 32-bit counter select PATCLKSEL0 Pattern generator clock selector Mux bit 0 PATCLKSEL1 Pattern generator clock selector Mux bit 1 LOCNTREN* Low counter count enable LOCNTRSEL* Low counter or pattern select...

  • Page 54: Table 4-2: Pattern Generator Clock Select Truth Table

    Theory of Operation Table 4–2: Pattern generator clock select truth table PATCLKSEL0 PATCLKSEL1 Clock select Sigclk2; Microprocessor timer2 used as clock TSTHD<3>; Setup and hold counter output bit 3 TSTHD<1>; Setup and hold counter output bit 1 CNTRCLK; Counter-pattern generator master clock The Sigclk2 clock is the microprocessor timer2 output which can be pro- grammed to any frequency and duty cycle.
  • Page 55 Theory of Operation Setup and Hold Trigger Signals. The setup and hold signals (schematic 25) are generated by a four-bit counter clocked at a 50 MHz rate. The four bits of the counter connect to four signal ground square pin pairs so they can be measured by a logic analyzer or by an oscilloscope.

  • Page 56: Table 4-5: Locntrsel Bit Operation

    Theory of Operation The setup and hold violation counter operates in the following manner. The four-bit counter has a continuous count at 50 MHz. The four output bits and the clock can be measured. However, the clock is skewed in time at a specific counter output bit pattern of 1010.
  • Page 57 Theory of Operation Glitch Signal. The glitch signal (schematic 28) is generated by gating the microprocessor programmable timers. The timers can be changed in frequency and duty cycle. The actual glitch signal is generated by delaying one of the timer signals into an exclusive-or gate with a resistor-capacitor network.

  • Page 58: User Interface Module

    Theory of Operation User Interface Module The user interface module (schematic sheets 8 and 9) provides a means to control and observe the actions of the hardware features on the training board. LCD Display. The main display device is a two by 16 character LCD display. The readout is controlled by software and by the four push-button switches.

  • Page 59: Input And Output Connectors

    Theory of Operation Input and Output Connectors The TLA 7QS Training Board has the following input and output port connec- tors: Two serial ports A logic analyzer control port Two external trigger BNC connectors A background debug mode connector A JTAG connector (pins not installed on board) Power input connectors Bus interface connector Probe interfaces...
  • Page 60 Theory of Operation Figure 4–2: Input and output connector locations 4–10 TLA QuickStart Technical Reference Manual...

  • Page 61: Serial Ports

    Theory of Operation Serial Ports The main serial port, J500, (schematic 18) is a nine-pin subminiature D-connec- tor that provides an RS-232 serial interface for controlling the computer system and for reading program data. This serial port uses the integrated serial port B of the M68340 microprocessor.

  • Page 62: Table 4-9: Logic Analyzer Control Port Signals (J400)

    Theory of Operation Logic Analyzer Control The logic analyzer control port (schematic 19) is a 25-pin subminiature Port D-connector and provides parallel input and output control signals for monitor- ing and controlling the training board hardware and software. The port is compatible with any version of the standard PC parallel interface port.

  • Page 63: External Trigger Bnc Connectors

    Theory of Operation External Trigger BNC Two external trigger BNC connectors (schematic 20) provide input and output Connectors trigger connections. External Trigger Input Signal Connector (J700). This connector is an input for TTL-level signals. The signal connects to the microprocessor interrupt request level 5 input line and is gate-enabled through software control.

  • Page 64: Jtag Port

    The Bus Interface connector, J180, (schematic 11) provides a means for connecting the training board to other test fixtures. The connector is a standard 3 by 32 male receptacle DIN connector. Use a 3 by 32 female connector (Tektronix part number 131–2950–00 or similar) to connect to this connector.

  • Page 65: Table 4-12: Bus Interface Connector (J180)

    Theory of Operation Table 4–12: Bus interface connector (J180) Row A signal Row B signal Row C signal DATA0 PORTA7 DATA8 DATA1 PORTA6 DATA9 DATA2 PORTA5 DATA10 DATA3 PORTA4 DATA11 DATA4 PORTA3 DATA12 DATA5 PORTA2 DATA13 DATA6 PORTA1 DATA14 DATA7 PORTA0 DATA15 Ground...

  • Page 66: Probe Interfaces

    This provides connections for 96 data channels and six clock channels. The data channels and clock channels connect to the 68340 microprocessor and the related control lines. The signals are compatible with the Tektronix 68340 microproces- sor control package. The counter and pattern generator signals can be probed with standard logic analyzer probes on two by eight square-pin headers.

  • Page 67: Functional Verification

    Logic analyzer TLA 700 Series TLA 711 Benchtop Chassis or TLA 704 Portable Mainframe Logic analyzer module 102 channel or 136 channel TLA 700 Series Logic TLA 7M3, TLA 7M4, TLA 7L3 Analyzer Module or TLA 7L4 Logic Analyzer Probes 6 P6417 Probes and 3 P6434 Probes –...

  • Page 68: Microprocessor Circuitry Check

    Functional Verification Procedures Microprocessor Circuitry Check The following checks verify the functionality of the microprocessor circuitry on the training board. This procedure is based on the microprocessor exercises in the TLA 7QS Training Manual. NOTE. To complete the functional check procedure, it is assumed that the TLA 7QS application software and Microprocessor Analysis software files are installed on the logic analyzer.
  • Page 69 Functional Verification Procedures 2. Use the UP or DN buttons on the training board to select the PATTERN GEN program. 3. Push the RUN button on the training board to start the pattern generator program. 4. On the logic analyzer, restore the default setups (select Default System from the File menu).

  • Page 70: Digital And Analog Circuitry Check

    Burst pulse Fast edge signal Metastable glitch signal Staircase signal To complete these checks, you will need a 1 GHz analog bandwidth oscilloscope and an oscilloscope probe (Tektronix TDS 684B with a P6345 probe). 5–4 TLA QuickStart Technical Reference Manual...

  • Page 71: Runt Pulse And Missing Pulse Check

    Functional Verification Procedures Runt Pulse and Missing Perform the followings steps to verify basic functionality of the runt pulse and Pulse Check missing pulse. 1. Set up the vertical input of the oscilloscope to measure a 2 V pulse. 2. Set horizontal controls as follows: Time/Div 100 ns Position...

  • Page 72: Burst Pulse Check

    Functional Verification Procedures 4. Connect the Channel 1 probe to the PULS pin on the training board (J870–5). Connect the probe ground lead to a nearby ground pin. 5. Adjust the trigger level control on the oscilloscope for a positive pulse (the pulse may have some jitter).

  • Page 73: Metastable Glitch Signal Check

    Functional Verification Procedures 3. Set up the trigger controls as follows: Type Edge Source Slope Rising Level 220 mV 4. Connect the Channel 1 probe to the EDGE pin on the training board (J870–7). Connect the probe ground lead to a nearby ground pin. 5.

  • Page 74: Staircase Signal Check

    Functional Verification Procedures Staircase Signal Check Perform the followings steps to verify basic functionality of the staircase signal. 1. Set up the vertical input of the oscilloscope to measure a 200 mV signal. Set the position two divisions below the center graticule. 2.

  • Page 75: Maintenance

    4. Nothing capable of generating or holding a static charge should be allowed on the work station surface. Service Strategy Tektronix provides service to cover repair under warranty as well as other services that may provide a cost-effective answer to your service needs. Warranty Repair Service Tektronix warrants the training board for three months from the date of shipment.

  • Page 76: Repair Or Calibration Service

    Training Board Of these services, the annual prearranged service offers a particularly cost-effec- tive approach to service for many owners of the TLA 700 series logic analyzers. Self Service Tektronix supports repair to the module level by providing Module Exchange.

  • Page 77: Troubleshooting Procedures

    CAUTION. Avoid using chemical cleaning agents that might damage the plastics and external labels used on the training board. Use a cloth dampened with water to clean external surfaces. Before using any cleaner, consult your Tektronix Service Center or representative.
  • Page 78 Maintenance If the training board is being shipped to a Tektronix Service Center, enclose the following information: The owner’s address Name and phone number of a contact person Type and serial number of the training board Reason for returning A complete description of the service required Seal the shipping carton with an industrial stapler or strapping tape.

  • Page 79: Replaceable Parts

    This section contains a list of the electrical components for the TLA 7QS training board. Use this list to identify and order replacement parts. Parts Ordering Information Replacement parts are available through your local Tektronix field office or representative. Changes to Tektronix products are sometimes made to accommodate improved components as they become available and to give you the benefit of the latest improvements.

  • Page 80: Abbreviations

    Chassis-mounted parts have no assembly number prefix, and they are located at the end of the electrical parts list. Tektronix part number Use this part number when ordering replacement parts from Tektronix. 3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column four indicates the serial number at which the part was discontinued.
  • Page 81 Replaceable Electrical Parts Manufacturers cross index Mfr. code Manufacturer Address City, state, zip code 00779 AMP INC. CUSTOMER SERVICE DEPT HARRISBURG, PA 17105–3608 PO BOX 3608 01295 TEXAS INSTRUMENTS INC SEMICONDUCTOR GROUP DALLAS, TX 75272–5303 13500 N CENTRAL EXPRESSWAY PO BOX 655303 04222 AVX/KYOCERA PO BOX 867...
  • Page 82 76493 BELL INDUSTRIES JW MILLER DIVISION GARDENA, CA 90247–1059 306 E ALONDRA BLVD PO BOX 2859 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON, OR 97077–0001 PO BOX 500 91637 DALE ELECTRONIC COMPONENTS 1122 23RD ST COLUMBUS, NE 68601...
  • Page 83 Replaceable Electrical Parts Replaceable electrical parts list Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number 671–3684–00 CIRCUIT BOARD:LA QUICKSTART 80009 671–3684–00 A01C130 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R 04222 0603YC104MAT2A A01C150 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R...
  • Page 84 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01C480 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R 04222 0603YC104MAT2A A01C0481 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R 04222 0603YC104MAT2A A01C482 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R...
  • Page 85 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01C0621 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R 04222 0603YC104MAT2A A01C622 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R 04222 0603YC104MAT2A A01C650 283–5353–00 CAP,FXD,CERAMIC:0.1UF,20%,16V,X7R,0603,SMD,T&R...
  • Page 86 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01C0214 283–5114–00 CAP,FXD,CERAMIC:MLC,0.1UF,10%,50V,X7R,1206,SMD,8MM 04222 12065C104KAT(1A T&R OR 3A) A01CR120 152–5084–00 DIODE,RECT:SCHTKY,40V,3A,80A 04713 MBRS340T3 IFSM,MBRS340,DO–214AB/SMC,16MM T&R...
  • Page 87 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01J430 131–5267–00 CONN,HDR:PCB,MALE,STR,2 X 40,0.1 CTR,0.235 MLG X 0.110 00779 104326–4 TAIL,30GOLD, HIGH TEMP, A01J440 131–5267–00...
  • Page 88 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01J771 131–4917–00 CONN,HDR:PCB,MALE,STR,1 X 2,0.1 CTR,0.235 MLG X 0.110 00779 104350–1 TAIL,30 GOLD,TUBE,HIGH TEMP, A01J800 131–5999–00...
  • Page 89 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01Q680 151–5000–00 TRANSISTOR,SIG:BIPOLAR,PNP,40V,200MA,250MHZ,AMPLIFIE 04713 MMBT3906LT1 R,MMBT3906L,TO–236/SOT–23,8MM T&R A01R180 321–5425–00 RES,FXD,FILM:4.75K,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW06034751FR T–1 A01R181 321–5432–00...
  • Page 90 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01R482 321–5425–00 RES,FXD,FILM:4.75K,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW06034751FR T–1 A01R483 321–5432–00 RES,FXD,FILM:100K,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW06031003FR T–1 A01R484 321–5432–00...
  • Page 91 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01R584 321–5425–00 RES,FXD,FILM:4.75K,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW06034751FR T–1 A01R585 321–5415–00 RES,FXD,FILM:0 OHM JUMPER,100V,62MW,0603,SMD,T&R 59124 RM73Z1J000ZT A01R0610 307–5041–01...
  • Page 92 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01R685 321–5454–00 RES,FXD,FILM:332 OHM,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW0603332RFR T–1 A01R700 321–5445–00 RES,FXD,FILM:49.9 OHM,1%,100V,62.5MW,0603,SMD,T&R 91637 CRCW060349R9FR T–1...
  • Page 93 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01U0270 156–6151–01 IC,MEMORY:CMOS,SRAM,128K X 62786 HM628128LFP–10S 8,100NS,15UA,OE,431000,SO32.440,T&R A01U271 156–6663–00 IC,MEMORY:CMOS,EPROM,128K X 8,120NS,5V 34335 AM29F010–120JC...
  • Page 94 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01U0570 156–5085–01 IC,DIGITAL:HCTCMOS,GATE,QUAD 2–INPUT 04713 MC74HCT32ADR2 OR,74HCT32,SO14.150,16MM T&R A01U0571 156–5085–01 IC,DIGITAL:HCTCMOS,GATE,QUAD 2–INPUT 04713 MC74HCT32ADR2 OR,74HCT32,SO14.150,16MM T&R...
  • Page 95 Replaceable Electrical Parts Replaceable electrical parts list (Cont.) Component Tektronix Serial no. Serial no. Mfr. number part number effective discont’d Name & description code Mfr. part number A01U810 156–5510–00 IC,DIGITAL:FTTL,COUNTER,SYNCH 4–BIT UP/DOWN 01295 SN74F169D BINARY,PRESET,74F169,SO16.150 A01U0811 156–5510–00 IC,DIGITAL:FTTL,COUNTER,SYNCH 4–BIT UP/DOWN...

  • Page 96: Diagrams And Circuit Board Illustrations

    The circuit board illustration appears only once; its lookup table lists the diagram number of all diagrams on which the circuitry appears. Other standards used in the preparation of diagrams by Tektronix, Inc., include the following: Some of the circuit board component location illustrations are expanded and divided into several parts to make it easier for you to locate small components.
  • Page 97 J700 J800 J200 J600 J111 J500 J400 CR800 J601 C800 C211 C213 R800 R900 J110 C710 CR801 R810 R811 R500 R501 C610 U810 U812 U910 U712 C411 Y610 S110 U511 DS210 R210 C622 C720 U723 U821 U824 U920 L310 L410 C421 R511 R512...
  • Page 98 C0612 C0711 R0611 C0611 C0410 R0311 R0310 U0911 U0813 U0713 U0811 U0711 U0410 U0510 U0610 U0210 U0921 U0825 U0823 U0724 Q0310 CR0310 C0721 C0620 C0523 C0522 C0521 C0520 C0422 C0621 C0420 U0230 C0240 U0250 C0151 R0460 U0660 U0462 U0562 U0360 R0462 C0460 U0260...
  • Page 99 A01 TLA 7QS Quickstart Training Board Component Locator CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM CIRCUIT BOARD SCHEM NUMBER LOCATION LOCATION NUMBER LOCATION LOCATION NUMBER LOCATION LOCATION NUMBER LOCATION...
  • Page 100 TLA 7QS MICROCONTROLLER.PROCESSOR...
  • Page 101 TLA 7QS MICROCONTROLLER.FLASH/EEPROM/NVRAM...
  • Page 102 TLA 7QS MICROCONTROLLER.SRAM...
  • Page 103 TLA 7QS MICROCONTROLLER.INTERRUPTLOGIC...
  • Page 104 TLA 7QS MICROCONTROLLER.CNTROLSIGS...
  • Page 105 TLA 7QS MICROCONTROLLER.CONTROLBITS...
  • Page 106 TLA 7QS MICROCONTROLLER.FUNCTIONKEYS...
  • Page 107 TLA 7QS MICROCONTROLLER.LEDDISPLAY...
  • Page 108 TLA 7QS MICROCONTROLLER.DELAYGEN...
  • Page 109 TLA 7QS MICROCONTROLLER.BUSEXTENDER...
  • Page 110 TLA 7QS CIRCUITBOARD.POWERSUPPLY...
  • Page 111 TLA 7QS PROBEADAPTER.LASI3ADAPTER...
  • Page 112 TLA 7QS PROBEADAPTER.LASI3ADAPTER...
  • Page 113 TLA 7QS PROBEADAPTER.LASI3ADAPTER...
  • Page 114 TLA 7QS PROBEADAPTER.LASI14INTERFACE...
  • Page 115 TLA 7QS PROBEADAPTER.LASI4ADAPTER...
  • Page 116 TLA 7QS CONTROLPORTS.SERIALPORTS...
  • Page 117 TLA 7QS CONTROLPORTS.LAPORT...
  • Page 118 TLA 7QS CONTROLPORTS.MONITORPORTS...
  • Page 119 TLA 7QS SIGNALSOURCES.HEADERS...
  • Page 120 TLA 7QS SIGNALSOURCES.LOCOUNTER...
  • Page 121 TLA 7QS SIGNALSOURCES.HICOUNTER...
  • Page 122 TLA 7QS SIGNALSOURCES.COUNTERLOGIC...
  • Page 123 TLA 7QS SIGNALSOURCES.SETUPHOLDGEN...
  • Page 124 TLA 7QS SIGNALSOURCES.RUNTS&METAGEN...
  • Page 125 TLA 7QS SIGNALSOURCES.STAIRCASE...
  • Page 126 TLA 7QS SIGNALSOURCES.EDGE/PULSE...
  • Page 127 TLA 7QS SIGNALSOURCES.BURSTGEN...
  • Page 128 TLA 7QS CIRCUITBOARD.MISCPARTS...

  • Page 129: Parts Ordering Information

    This section contains a list of the replaceable mechanical components for the TLA 7QS training board. Use this list to identify and order replacement parts. Parts Ordering Information Replacement parts are available through your local Tektronix field office or representative. Changes to Tektronix products are sometimes made to accommodate improved components as they become available and to give you the benefit of the latest improvements.

  • Page 130: Abbreviations

    Items in this section are referenced by figure and index numbers to the exploded view illustrations that follow. Tektronix part number Use this part number when ordering replacement parts from Tektronix. 3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column four indicates the serial number at which the part was discontinued.
  • Page 131 910 PAGE AVE 73743 FISCHER SPECIAL MFG CO 111 INDUSTRIAL RD COLD SPRINGS, KY 41076 PO BOX 76500 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON, OR 97077–0001 PO BOX 500 85480 BRADY USA NAMEPLATE DIVISION HILLSBOROUGH, NC 27278...
  • Page 132 Replaceable Mechanical Parts Replaceable parts list Fig. & Tektronix Serial no. Serial no. index part number effective discont’d Name & description Mfr. code Mfr. part number number 8–1–1 671–3684–00 CIRCUIT BOARD:LA QUICKSTART 80009 671–3684–00 – 334–5026–00 MARKER,IDENT:MKD BLANK 85480 ORDER BY DESCR –2...
  • Page 133 Replaceable Mechanical Parts Figure 8–1: Exploded view 8–5 TLA QuickStart Technical Reference Manual...
  • Page 134 Replaceable Mechanical Parts Replaceable parts list (Cont.) Fig. & Tektronix Serial no. Serial no. index part number effective discont’d Name & description Mfr. code Mfr. part number number 8–1–20 131–3358–00 CONN,HDR:PCB,MALE,RTANG,2 X 5,0.1 CTR,0.390 53387 2510–5002UB MLG X 0.112 TAIL,0.33 H,SHRD/4 SIDES,MIL PLZ (J200, J600) –21...

  • Page 135: Appendix A: Source Code

    Appendix A: Source Code This appendix contains information on the source code available with the standard training board as it is shipped from the factory. System Source Code Files Table A–1 lists some of the system source code files available with the TLA 7QS software.

  • Page 136: Sample Programs

    Appendix A: Source Code Table A–1: TLA 7QS System software files (Cont.) File Description Timer.s Assembly language to configure the 68340 timers Mongoose.a Precompiled ROM portion of the SDS target monitor Mongoose.obj Firmware object file Sample programs The following programs are included with this manual to provide examples of creating user programs to work with the training board.

  • Page 137: Build.bat

    Appendix A: Source Code build.bat This build.bat file is an MSDOS batch file that will compile, link and prepare for download the sample C program named User.c. A–3 TLA QuickStart Technical Reference Manual...

  • Page 138: Combine.spc

    Appendix A: Source Code combine.spc This combine.spc file is a linker specification file that will map partitions and regions to specific memory locations that match the requirements for the training board. For more information, refer to the SDS Linker documentation. A–4 TLA QuickStart Technical Reference Manual...
  • Page 139 Appendix A: Source Code A–5 TLA QuickStart Technical Reference Manual...

This manual is also suitable for:

Tla 7qs

Table of Contents
