Instructions
TLA 7F1
TLA 700 Series Logic Analyzer DRAM and
Hard Disk Drive Upgrade Installation
070-9838-00
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.
Advertisement
Related Manuals for Tektronix TLA 7F1
Summary of Contents for Tektronix TLA 7F1
- Page 1 Instructions TLA 7F1 TLA 700 Series Logic Analyzer DRAM and Hard Disk Drive Upgrade Installation 070-9838-00 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so.
- Page 2 Copyright Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A. Tektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000...
-
Page 3: Service Safety Summary
Service Safety Summary Only qualified personnel should perform service procedures. Read this Service Safety Summary and the safety summaries in your product manual before performing any service procedures. Do Not Service Alone. Do not perform internal service or adjustments of this product unless another person capable of rendering first aid and resuscitation is present. -
Page 4: Kit Description
Quantity Part number Description 156-7503-00 16 MB SIMMs 119-5607-00 2.16 GB Hard Disk Drive 342-1027-00 Lexan Insulator 070-9838-00 TLA 7F1 Installation Instructions TLA 7F1 Kit Label TLA 7F1 Shipping List TLA 700 Series DRAM and Hard Disk Drive Upgrade Installation... - Page 5 TLA 704 Color Portable Mainframe Service Manual. Contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service Center for installa- tion assistance. CAUTION. To prevent static discharge damage, service the instrument only in a static-free environment.
- Page 6 Installation Instructions Disassembly You will need a screwdriver with a size T-15 Torx tip to perform this procedure. 1. Disconnect the power cord from the mainframe. 2. Remove the modules and probes from the mainframe. 3. Set the mainframe on your work surface with the cord wrap feet facing down and with the bottom facing you.
- Page 7 Installation Instructions Cover To remove the trim ring, grasp its bottom edge and flex it toward you before pulling upward. Trim ring Remove screws (4) Figure 1: Front cover and trim ring removal TLA 700 Series DRAM and Hard Disk Drive Upgrade Installation...
- Page 8 Installation Instructions 8. Set the mainframe on your work surface with the bottom facing down and the front facing you. (See Figure 2.) 9. Remove the accessories pouch from the top cover. (It unsnaps.) 10. Remove the four screws that attach the top cover to the mainframe. NOTE.
- Page 9 Installation Instructions 13. Remove the five screws that attach the flat panel display assembly to the mainframe. (See Figure 3.) 14. Lift the bottom edge of the flat panel display assembly and rotate it upward and off the front face of the mainframe. 15.
- Page 10 Installation Instructions RAM SIMMs Replacement You will need a screwdriver with a size T-15 Torx tip to perform this procedure. Removal Use the following procedure to remove the RAM SIMMs: 1. Set the mainframe on your work surface with the bottom facing down and with the left side facing you.
- Page 11 Installation Instructions Press outward Press Hard disk outward drive, bracket SIMM boards (2) Press outward Press outward Figure 4: SIMM boards and hard disk drive replacement TLA 700 Series DRAM and Hard Disk Drive Upgrade Installation...
-
Page 12: Hard Disk Drive Replacement
Installation Instructions Hard Disk Drive Replacement You will need screwdrivers with a size T-15 Torx tip and a size T-10 Torx tip to perform this procedure. Removal Use the following procedure to remove the hard disk drive: 1. Locate the hard disk drive in Figure 4 on page 11. 2. -
Page 13: Verify Operation
Installation Instructions 4. Reposition the left side cover. 5. Reposition the top cover on the portable mainframe. 6. Install the four screws that attach the top cover to the mainframe. 7. Reattach the accessories pouch to the top cover. (It snaps on.) 8. - Page 14 Controller subassembly. If you are not familiar with servicing the instrument, it is strongly recommended that you contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service for installation. CAUTION. To prevent static discharge damage, service the instrument only in a static-free environment.
- Page 15 Installation Instructions Disassembly Verify that the power cord has been disconnected from the mainframe. Remove any connected cables or probes from the benchtop controller and remove the benchtop controller from the mainframe. You will need a T-9 Torx tip driver to remove the left side cover and rear panel. 1.
- Page 16 Installation Instructions You will need a T-9 Torx tip driver, a small flat-bladed screwdriver, a #0 Phillips screwdriver, a #1 Phillips screwdriver, a 3/16 inch nut driver, and a needle nose plier to remove the Controller subassembly. NOTE. The following steps remove the subassembly from the enclosure to gain access to the internal parts.
- Page 17 Installation Instructions Remove screws (6) Chassis Figure 7: Subassembly removal CAUTION. The subassembly is attached to the chassis by the four SMB connector cable assemblies. To avoid damaging the subassembly, use care when lifting the subassembly out. 11. Carefully lift the subassembly part way out of the chassis. 12.
- Page 18 Installation Instructions RAM SIMMs Replacement The RAM SIMMs are located on the Controller board of the subassembly that you just removed. (See Figure 8.) Removal and installation of the SIMM boards do not require the use of tools. Removal 1. Press outward on the clips holding each SIMM board to the Controller board and lift off the SIMM board.
- Page 19 Installation Instructions Hard Disk Drive Replacement You will need a #0 Phillips screwdriver and a #1 Phillips screwdriver. Removal The hard disk drive is mounted to the Adapter board, which must be separated from the Controller board in order to replace the hard disk drive. Refer to Figure 9 and follow these steps: 1.
- Page 20 Installation Instructions Remove screws (5) Squeeze to remove Controller board Brown Orange Disconnect SMB cable assemblies (4) White Disconnect ribbon cables (2) Center standoff Adapter board Figure 9: Controller board and Adapter board interconnection 4. Remove the four Phillips screws securing the hard disk drive to the solder side of the Adapter board.
- Page 21 Installation Instructions Hard disk drive Remove screws (4) Figure 10: Hard disk drive removal Installation To install the hard disk drive you will need a #0 Phillips screwdriver and a #1 Phillips screwdriver. 1. Peel the backing off of the Lexan insulator included in the kit and apply it to the hard disk drive.
- Page 22 Installation Instructions Lexan insulator Hard disk drive Align with edge Pins Figure 11: Applying the Lexan insulator 2. Carefully align the connector pins on the back of the hard disk drive to the socket on the Adapter board. Gently slide the hard disk drive into the socket. Verify that all of the pins are fully engaged and that no pins are bent.
- Page 23 Installation Instructions 2. Carefully turn the subassembly over and connect the four SMB cable assemblies to the four SMB connectors on the Controller board. Figure 9 on page 21 shows the locations for plugging in the four connectors. Table 2 identifies each connector by color code and signal name.
- Page 24 Installation Instructions b. Click Start in the Windows 95 tool bar. c. Select Programs from the Start menu. d. Select the QAPlus application from the Programs menu. e. Run the memory and hard disk drive tests from the QAPlus menu. If needed, refer to the QAPlus online help for more information on running QAPlus.
