Mounting the dash
To be able to mount the dash on the hardware of your choice, we provide adapter
plates. Which one you have will depend on your purchase and may different from
the following one we show.
A6
A8
A4
OSW/Simucube/VRS
Loosen the existing upper bolts which hold the motor in place. Simply slide the
adapter plate over the exposed thread and tighten the bolts against the plate.
Note: the adapter plate for a Simucube Ultimate is sold separately.
3
3 11
|
