Changing the LEDs' functions.
To change the LED effects you need to now the LED numbering of the dash. The
numbering starts at the bottom left and continues clockwise to the bottom right.
See the image below for reference:
6 7 8 9 10
5
4
3
2
1
There should be enough info in the sample profile to be able to adjust to your liking.
Just keep in mind, you mostly need two values. The number of the LED where you
want an effect to start, and the amount of LEDs to use for said effect (in a clockwise
direction).
For further assistance and more information on effects, please see the SimHub
documentation.
11 12 13 14 15 16 17 18

Bill of materials

IN THE BOX
# Part
19
A1 Dash SD43-LED
20
A2 USB B Cable
21
22 A3 Adapter plate Fanatec
23
A4 Adapter OSW/SC/VRS
A5 Bolt M6 X 12 DIN 912
A6 Bolt M5 X 10 DIN 7380
A7 Washer M6 DIN 125-A
A8 Washer M5 DIN 125-A
Disclaimer: for some entries on this list, we supply more than required as
spare materials. Don't worry if you have some leftovers, this is intentional.
QTY Note
1
1
1 Fits all Fanatec hardware.
1
2
4 To fit adapter plate to dash.
4
4
10
10 11 |
