- Page 1 Helicon ™ S10/S40 Spiral Cartridges Installation Guide NOTICE The configuration of Helicon S40 cartridges has been changed: ™ the limited by-pass seal (the “chevron”) has been moved to the inlet end. Please follow these installation instructions carefully.
- Page 2 Corporation assumes no responsibility for any errors that may appear in this document. This manual is believed to be complete and accurate at the time of publication. In no event shall Millipore Corporation be liable for incidental or consequential damages in connection with or arising from the use of this manual.
-
Page 3: Table Of Contents
Contents Introduction ......................5 Safety and Environmental Compliance ..............5 S10: Installing an S10 Cartridge in the S10 Housing ..........6 S10: Flushing and Cleaning ................7 S10: Integrity Testing ..................8 S40: Installing an S40 Cartridge in the S40 Housing .......... 10 S120: Installing Three S40 Cartridges in the S120 Housing ......... -
Page 4: Introduction
Helicon S40 cartridges in an S120 housing. Safety and Environmental Compliance Helicon S10 and S40 cartridges are packaged in a 3% formaldehyde solution. Therefore, gloves and other appropriate safety equipment must be worn during the installation of the cartridge. The bag in which the cartridge is shipped and the used gloves, etc., must be disposed of appropriately. -
Page 5: S10: Installing An S10 Cartridge In The S10 Housing
S10: Installing an S10 Cartridge in the S10 Housing Installation of the cartridge requires the S10 header kit (Millipore Cat. No. 540605). The kit may be reused. For replacement of individual components, please see the parts list provided with the kit. -
Page 6: S10: Flushing And Cleaning
5. Operate the pump only until the system is drained. Flush #2: 1. Repeat the water flush, as outlined in Flush #1 above. 2. Immediately perform the integrity test, as described in the following section. Helicon S10/S40 Spiral Cartridges Installation Guide... -
Page 7: S10: Integrity Testing
4. Slowly raise the gas pressure to the value recommended for your cartridge type, as shown in Table 1. Table 1. Integrity Test Specifications for S10 Catalogue Gas Flow Rate Test Pressure Number cc/min psig (bar) ≤ 60 CDUF010LC 10 (0.7) ≤ 60 CDUF010LG 5 (0.35) ≤ 150 CDUF010LT 5 (0.35) www.millipore.com... - Page 8 Millipore Technical Service for assistance. If the measured gas flow rate does not exceed the specified gas flow rate, the cartridge passes the test. Reconnect the process line to the cartridge and resume operation. Helicon S10/S40 Spiral Cartridges Installation Guide...
-
Page 9: S40: Installing An S40 Cartridge In The S40 Housing
(the “chevron”) has been moved to the inlet end. Please follow these installation instructions carefully. The S40 cartridge hardware kit (Millipore Cat. No. 540700) incorporates all the hardware that is required for installation of a single S40 cartridge. The kit may be reused. - Page 10 3. Inspect the white silicone chevron (limited by-pass) seal for nicks or cuts. NOTE: If a seal is damaged, do not use the cartridge. A defective new cartridge may be returned to Millipore for replacement. 4. Lubricate the permeate connector O-ring with pure glycerin.
-
Page 11: S120: Installing Three S40 Cartridges In The S120 Housing
(the “chevron”) has been moved to the inlet end. Please follow these installation instructions carefully. The S120 Cartridge Hardware Kit (Millipore Cat. No. 540710) is required for installation of the cartridges. The kit may be reused. For replacement of individual components, please see the parts list provided with the kit. - Page 12 2. Using a gentle twisting motion, join the cartridges together: a. Push cartridge #2 over the connector extending from the outlet end of cartridge #1. b. Push cartridge #3 onto the connector extending from the outlet end of cartridge #2. Helicon S10/S40 Spiral Cartridges Installation Guide...
- Page 13 Chevron seal Cartridge connector Chevron Housing sleeve (limited by-pass) seal Cartridge #2 Cartridge connector Permeate tube Cartridge #1 Chevron seal Clamp Permeate connector Gasket Permeate port Inlet header Figure 8. Installation of three S40 cartridges in an S120 housing www.millipore.com...
- Page 14 15. Clamp the sleeve and outlet header together, tightening the bolts evenly until the header is secure. After installation, follow the instructions in the sections S40/S120: Flushing and Cleaning and S40/S120: Integrity Testing. Integrity test specifications for three S40 cartridges in an S120 housing are provided. Helicon S10/S40 Spiral Cartridges Installation Guide...
-
Page 15: S40/S120: Flushing And Cleaning
4. Direct the retentate and permeate lines to the drain. 5. Operate the pump only until the system is drained. Flush #2: 1. Repeat the water flush, as outlined in Flush #1 above. 2. Immediately perform the integrity test, as described in the following section. www.millipore.com... -
Page 16: S40/S120: Integrity Testing
Table 2. Integrity Test Specifications for S40 and S120 Gas Flow Rate Catalogue Test Pressure cc/min Number psig (bar) S120 ≤ 240 ≤ 720 CDUF040LC 10 (0.7) ≤ 240 ≤ 720 CDUF040LG 5 (0.35) ≤ 600 ≤ 1800 CDUF040LT 5 (0.35) Helicon S10/S40 Spiral Cartridges Installation Guide... - Page 17 If the gas flow rate remains in excess of the specified value, contact Millipore Technical Service for assistance. If the measured gas flow rate does not exceed the specified gas flow rate, the cartridge passes the test. Reconnect the process line to the cartridge and resume operation.
-
Page 18: Product Ordering Information
In the event of a breach of the foregoing warranty, Millipore’s sole obligation shall be to repair or replace, at its option, the applicable product or part thereof, provided the customer notifies Millipore promptly of any such breach. - Page 19 P60215, Rev. -, 04/02...
