Contemporary Controls BASstat Series User Manual page 29

Type &
Object name
Instance
Analog Minimum
Output
AV 11
Span Offset
AV 12
Low Setpoint Limit
AV 13
Type &
Object name
Instance
High Setpoint Limit
AV 14
Temperature Offset
Proportional Band-
Stage Width
AV 16
Stage Differential
UM-15090000-AA8
Readable/
Writable
R/W
R/W
R/W
Readable/
Writable
R/W
AV 15 R/W
R/W
AV 17 R/W
Description
Minimum Output Voltage in
Digital Value When Reach
Low Limit for AO1
Span Offset for AO1
Low Limit for Set-Point
Temperature
Description
High Limit for Set-Point
Temperature
Offset for Current
Temperature
Proportional Band or Stage
Width
Stage Differential
Range and Definition
0~125 (LSB)
-55~0 (LSB)
°C :0~500 (0.0～50.0℃)
°F: 320~1220
(32.0~122.0°F)
Range and Definition
°C :0~500 (0.0～50.0℃)
°F: 320~1220
(32.0~122.0°F)
°C: -100~100 (- 10.0~10.0
°C)
°F: -180~180 (-18.0~18.0
°F)
°C :0~100 (00~10.0 °C)
°F: 0~180 (00~18.0 °F)
°C :1~10 (0.1~1.0 °C)
°F: 1~18 (0.1~1.8 °F)
