Contemporary Controls BASstat Series User Manual page 28

Type &
Object name
Instance
Modulating/
AI 8
Floating Output 1
Modulating/
AI 9
Floating Output 2
Modulating Fan
AI 10
Output
Object name
Type &
Instance
CO2 Control Output
AI 11
Percentage
Voltage Input Value
AI 12
Analog Input 1
AI 13
Value
Analog Input 2
AI 14
Value
Analog Input 3
AI 15
Value
Cooling Temperature
Setpoint
AV 0
Space
Temperature
Via BACnet
AV 1
AV 2
Timer Off
Heating Temperature
Setpoint
AV 3
Hr-Running Time
AV 4
M-Running Time
AV 5
Sec-Running
Time
AV 6
Deadband
AV 7
Unoccupied Cool
AV 8
Setpoint
Unoccupied Heat
AV 9
Setpoint
Integral-Cycle
AV 10
Time
UM-15090000-AA8
Readable/
Description
Writable
Modulating/ Floating Output
R
1
Modulating/ Floating Output
R
2
Modulating Fan Output
R
Description
Readable/
Writable
CO2 Control Output
R
Percentage
Voltage Input Value
R
Analog Input 1 Percentage
R
Value
Analog Input 2 Percentage
R
Value
Analog Input 3 Percentage
R
Value
Cooling Temperature Set
Point
R/W
BACnet Assigned
R/W
Current
Temperature
Timer Off (Only for Models
with Countdown Timer
R/W
Function
Available).
Heating Temperature Set
R/W
Point
Running Time of Valve (Hr.)
R/W
Running Time of Valve
R/W
(M.)
Running Time of Valve
R/W
(Sec.)
Deadband
R/W
Unoccupied Cooling Setpoint
R/W
Unoccupied Heating
R/W
Setpoint
Integral Time and Output
R/W
Cycle Time
Range and Definition
0~100: 0～100 %
0~100: 0～100 %
0~100: 0～100 %
Range and Definition
0~100: 0～100 %
0～150 (0.0～15.0 VDC)
0～1000 (0.0%～100.0%)
0～1000 (0.0%～100.0%)
0～1000 (0.0%～100.0%)
°C :0~500 (0.0～50.0℃)
°F: 320~1220
(32.0~122.0°F)
-999~9999
(-99.9～999.9℃/°F)
0~24: 0~24 Hours Count
Down
0: Disable
℃/°F
-999~9999: -99.9～999.9
0~65535 (Hr.) For
Reading But 0~30000 (Hr.)
For Writing.
0~59 (Minute)
0~59 (Sec.)
°C: 0~100 (0.0~10.0 °C)
°F: 0~180 (00~18.0 °F)
°C: 250~300 (25.0~30.0°C)
°F: 770~860 (77.0~86.0°F)
°C: 100~220 (10.0~22.0°C)
°F: 500~715(50.0~71.5°F)
0~500 (Sec.)
