Contemporary Controls BASstat Series User Manual page 31

Type &
Object name
Instance
Cooling Short Cycle
AV 23
Cooling Maximum
Cycles
per Hour
AV 24
Heating Short Cycle
AV 25
Heating
Maximum Cycles
per Hour
AV 26
Minimum Output for
AO2
AV 27
Span Offset for
AV 28
AO2
CO2 Input Low
AV 29
Value
CO2 Input High
AV 30
Value
CO2 Control Output
AV 31
Proportional Band
CO2 Setpoint
AV 32
CO2 Control
AV 33
Minimum Output
After Hour Extension
AV 34
Time
Input Low Value of
AV 35
Valve Feedback
Input High Value of
AV 36
Valve Feedback
Analog Input Low
AV 37
Value
Analog Input High
AV 38
Value
Humidity Input Low
Value
AV 39
Type &
Object name
Instance
Humidity Input High
Value
Minimum Fan
Output
AV 41
Maximum Fan
Output
AV 42
Low Fan Speed
AV 43
Setting
UM-15090000-AA8
Readable/
Writable
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Readable/
Writable
AV 40 R/W
R/W
R/W
R/W
Description
Cooling Short Cycle Delay
Cooling Maximum Cycles
per Hour
Heating Short Cycle Delay
Heating Maximum Cycles
per Hour
Minimum Output Voltage in
Digital Value When Reach
Low Limit for AO2
Span Offset for AO2
CO2 Input Low Value
CO2 Input High Value
CO2 Control Output
Proportional Band
CO2 Setpoint
CO2 Control Minimum
Output Percentage
After Hour Extension Run
Time
Input Low Value of Control
Valve Feedback
Input High Value of Control
Valve Feedback
Analog Input Low Value
Analog Input High Value
Humidity Input Low Value
Description
Humidity Input High Value
Minimum Fan Output at Auto
Fan Mode (for Modulating
Fan Application)
Maximum Fan Output at
Auto Fan Mode (for
Modulating Fan Application)
Low Fan Speed Setting (for
Modulating Fan Application)
Range and Definition
1~3 Minutes
2~6 Cycles
0~3 Minutes
2~8 Cycles
0~125 (LSB)
-55~0 (LSB)
0~1000 ppm
1000~3000 ppm
100~2000 ppm
600~1000 ppm
0~20%
5~20(0.5~2.0) Hour
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0
%RH)
Range and Definition
0~1000 (0.0～100.0
%RH)
0%~Reg 51
Reg 50~100%
0%~Reg 53
