Type &
Object name
Instance
AV 18
Lock
Control Out
Percentage
AV 19
MAC Address
AV 20
Type &
Object name
Instance
AV 21
Device Instance
AV 22
Humidity Offset
UM-15090000-AA8
Readable/
Description
Writable
RW
LOCK
Percentage of Modulating/
Floating Control Output
R/W
MAC address
R/W
Readable/
Description
Writable
R/W
BACnet Device Instance
Humidity Offset Value
R/W
(221CH models only)
Range and Definition
Bit Definition:
0: MODE button
(dec=1)
1: Down
buttons (dec=2)
2: Up button
(dec=4)
3: FAN SPEED button
(dec=8)
4: Power On/Off button
5: SET (or ℃/℉) button
(dec=16)
(dec=32)
6: ESI contact
detection (dec=64)
7: Door/Window
contact
detection (dec=128)
8: Modification for
communication
parameters (dec=256)
i.e. baud rate, MAC addr,
device inst.
9: Control DOs by
thermostat algorithm
(0) or BACnet sup. (1)
(dec=512)
10~15: reserved/unused
Bit Value
0: Unlock / enable
1: Lock / disable
Examples (add dec values to
lock multiples) For more details
see Lock Function Setup and
Examples section of this manual
0～100 (0%～100%)
0~127
Range and Definition
0~4194302
( Changing this value
NOTE:
needs to unlock modification
for communication
parameters in advance.
i.e. AV17=0~255 or
512~768. Please refer to
LOCK(AV17) for details)
-300~300 (-30.0～30.0
%RH)
