WIRELESS NETWORK IP CAMERA User's Guide
The Power LED is not
constantly lit
The network LED is off
The operating status
LED
Your Wireless Network
IP Camera works
locally, but not
externally.
The IP address is
located within a
different subnet
Other networking
problems
Faulty power supply
Faulty cabling
Faulty connecting
Firewall protection
Default routers required
The internet site is too
heavily loaded
58
Run the PING utility (as described in PINGing Your
IP Address, on page 39), If the utility returns "no
response" or similar, the diagnosis is probably
correct – you should then proceed as follows
In Windows 95/98 or Windows NT, check the IP
address for your Wireless Network IP Camera is
within the same subnet as your workstation:
1.Click "Start", "Settings", "Control Panel" and
"Network".
2.Specify the TCP/IP adapter and click on
"Properties". In Properties, Click "IP Address".
3.Check that the first 3 numbers within the IP
address of your Wireless Network IP Camera
matches the first 3 of your workstation. If not, your
Wireless Network IP Camera may be on a different
subnet and the IP address cannot be set from this
workstation. You must set the IP address for
Wireless Network IP Camera from a workstation on
the same subnet.
Trying replacing your network cable
Test the network interface of the product by
connecting a local computer to the unit, using a
standard Crossover (hub-to-hub) Cable.
If the above actions do not resolve the problem,
Wireless Network IP Camera maybe faulty, In this
case, try to localize the problem by connecting
Wireless Network IP Camera to the serial port of a
local computer, using the supported RS232 Cable
Verify that you are using an provided power supply
1.To verify that the cables are functional, PING the
address of a known existing unit on your network.
2.If the cabling is OK and your network is
reachable, your should receive the reply similar to
this:
. . . bytes = 32 time = 2 ms,
Verify that the power is well connected
Check the internet firewall with your system
manager
Check if you need to configure the default router
settings
Configure Wireless Network IP Camera to upload
your video images to an FTP server or an ISP
