WIRELESS NETWORK IP CAMERA User's Guide
ADJUSTING THE CAMERA LENS
Adjusting the Focus
In order for the Focus Assistant to access the full focusing range for your application environment,
simply turn the lens in the clockwise or counter clockwise direction; unless you want to replace the
lens, it should not be unscrewed more than 1.0mm.
*Adjust the camera focus while reviewing the picture quality on your Web browser.
A Good level of focus is normally achievable throughout several planes within the camera's
◆
focusing spectrum.
Since optimum focusing is dependent upon the camera's field of view, it is important to scan
◆
the focusing plane from the closest to furthest perspectives before attempting any fine-tuning
Lens
1.0mm max
NOTE
29
