INTELLINET ACTIVE NETWORKING 550710 – CGI Command Reference
CGI Command Reference V 1.3a for Network IP Camera
This documentation explains the usage of CGI commands which are supported by Network IP
Camera 550710.
There are five different categories of CGI commands:
1)
Still image request command
2)
Motion image request command
3)
GP_OUT Setting commands
4)
Setting Commands / Remote Programming
5)
Inquiry commands / Display of current settings & Alert State of Digital IO Connector
This reference is based on Firmware Version 4.11 (Released: February 17 2004).
You can get the latest firmware version here:
http://www.intellinet-network.com/ipcamera
http://www.intellinet-network.com/ipcamera
1 of 13
February 17 2004
