WIRELESS NETWORK IP CAMERA User's Guide
APPENDIX
A. Technical Specifications
Resolution: 640x480, 320x240, 160x120
Standard JPEG Compression – 10 levels of compressions
Network
10baseT Ethernet or 100baseTX Fast Ethernet
Twisted pair category 5 cables, Standard RJ45 connector
Supporting protocol: TCP/IP, UDP, PING, ARP, FTP, TFTP, and HTTP
Configuring is achieved by private setup program and Web server built in administration page.
Image Sensor
1/3" inch CMOS censor
326,688 pixels, 24-bit color, YUV digital output
Automatic exposure/Gain/White balance control
Image enhancement – brightness, contrast, gamma, saturation, sharpness, etc
664x492 pixel array elements
Electronic shutter: 1/30 s ~ 1/15734 s
Auto back light compensation: Automatic back light on or off depending on the lighting condition.
Lens specification
Replaceable standard CS mount lens
Focal length 6.0 mm, Angular field of view 54°, Object distance 0.1m to infinity
Maximum Relative aperture F1.8
C-Mount adapter available
Hardware
32bit RISC Net ARM CPU
ZORAN hardware compression chip
384 Kbytes video frame buffer
4M flash memory
SDRAM 8Mbyte
12V Power supply adapter included
