WIRELESS NETWORK IP CAMERA User's Guide

Replacing the Lens

Because Wireless Network IP Camera is designed with a CS-Mount, the lens supplied with
your product can be replaced with any standard C or CS lens, typically used within the
surveillance industry.
Follow the instructions below to replace the supplied lens with any C or CS type lens:
1. Unscrew Wireless Network IP Camera lens turning the lens in the anti clockwise
2. C-lens only: Attach the new lens to a C-CS Adapter
3. Screw the new lens onto Wireless Network IP Camera. If applicable, adjust the iris according
to
the prevailing light conditions.
4. Referring to Focusing the Camera under quiescent conditions, on page 29, Adjusting the focus.
5. Reload your Web browser and monitor the results from the product Home Page.
30
