IKEA SMAKSAK 704.116.73 Manual page 12

ENGLISH
Step 3 Close the oven door halfway to the
first opening position. Then lift and
pull to remove the door from its
seat.
Step 4 Put the door on a soft cloth on a sta‐
ble surface.
Step 5 Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
Step 6 Pull the door trim to the front to re‐
move it.
Step 7 Hold the door glass panels by their
top edge and carefully pull them out
one by one. Start from the top pan‐
el. Make sure the glass slides out of
the supports completely.
Step 8 Clean the glass panels with water and soap. Dry the glass panels carefully. Do
Step 9 After cleaning, install the glass panels, the door trim and the oven door, close
If the door is installed correctly, you will hear a click when closing the latches.
not clean the glass panels in the dishwasher.
the latches on the both hinges.
To download the full version visit www.ikea.com
